Hot Tire Curing Press For Retreading Tire

Specifications

1.Hot Tire Curing Press for retreading tire
2.Size: upto 57"
3.Segmented Mold
4.Heating by steam or oil

Hot Tire Curing Press for Retreading Tire



1. Replaceable internal mold within the certain range, of high flexibility and cost-effective.

2. Equipped with mechanical arm, easy for tire loading and unloading.

3. Special multi-interlock, guarantee the operating safety.

4. Heating from oil, steam, or electric.

5. All hydraulic controlled.

6. Optional center structure, curing bag or bladder.



Suitable size of Tire: 265/75R16, 9.00R20,10.00R20,12.00R24,14.00R25,16.00R25,20.5R25,23.5R25,...18.00R33,24.00R35...37.00R57,etc.



No.	Item	Parameter
1	Heating medium	steam or heating oil( suggest heat oil)
2	Available Maximum Inner Pressure	2.5Mpa
3	Compressed Air Control Pressure	0.3MPa
4	Hydraulic Pump Pressure	4MPa
5	Voltage	AC220V AC380V 50Hz
6	Temperature sensor points	2.( one is on tyre side, another on tread mold)
7	Temperature control precision	±2°C.





If you have such inquiry, welcome you send us your detailed requirement to us!
