Home > Manufacturing & Processing Machinery > Rubber Machinery > Rubber Product Making Machinery > Mechanical BOM Tire Curing Press

Mechanical BOM Tire Curing Press

Name: Mechanical BOM Tire Curing Press
Brand: PLASTSEA
SKU: 134087265
Availability: InStock

Mechanical BOM Tire Curing Press thumbnail-1

Mechanical BOM Tire Curing Press photo-1

US$ 120,000 - 180,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Place of Origin:

Shandong, China

Brand Name:

PLASTSEA

Contact Supplier Request Quote Chat Now

Qingdao Plastsea International Trade Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao seaport

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Place of Origin Shandong, China

Brand Name PLASTSEA

Model Number 41"45"46"48"

Voltage 380V

Certification CE

Warranty One year

After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.Mechanical Type
2.For PCR, LTR tire vulcanizing
3.41"45"46"48" Tire
4.Quality Guarantee and perfect after-sale service

Curing Press for PCR and LTR tyres (B-Type)

Plastsea This curing press is a mechanical type, the beam moves vertically and is tilting over for tyre loading and unloading. The center mechanism is BOM type and the curing mould is heated by platen. Other features of this type are: Dual-column vertical chuck loader, Dual-cylinder unloading device, Pro-Bar style mould stripping unit. As per customer’s request, auto mould-adjusting device,plassea, SMO drive device, PCI and single, double or triple position Green tyre holder is available. Curing piping can also be made to order.

This curing press uses PLC for real-time control and industrial PC for Human-Machine Operation Interface. All parameters can be re-set during curing cycle, and real-time data collection/ preservation.Plastsea, Alarming, as well as data back dating can also be realized through this system. With Ethernet interface, Plastsea Curing press group management is available.Plastsea

This curing press is applicable for curing PCR, LTR and bias tyres with Nitrogen or steam as curing medium.

Item		Unit	Specification
Item		Unit	1050	1145	1170	1220
Curing cavity No.			2	2	2	2
ID of Mould shield		MM	Φ1050	Φ1145	Φ1170	Φ1220
Max squeezing force plastsea		KN	1370x2	1715x2	1715x2	1800x2
Height of mould		MM	155-381	230-490	200-460	300-560
Center Mechanism			BOM	BOM	BOM	BOM
Diameter of suitable tyre bead		Inch	12-16	12-18	13-20	13-20
Max O.D. of cured tyre	Segmented mold	MM	770	800	850	850
Max O.D. of cured tyre	Two piece mold	MM	820	850	900	900
Max section width of cured tyre		MM	330	360	360	360
Max height of green tyre plastsea		MM	450	550	650	450
Designed mould open/close time		S	24/18	28/18	24/19	24/19
Max load of VCL		Kg	60	60	60	60
Max weight of mold		Kg	2500	2500	2500	3000
Max external pressure		Mpa	1.4
Max internal pressure		Mpa	2.8
Hydraulic water pressure		Mpa	1.8-2.1
Compressed air pressure		Mpa	0.7
Control air pressure		Mpa	0.25-0.35
PCI inflation pressure		Mpa	0.7
PCI rim width		MM	76-203	100-285	100-285	100-285
