Tyre curing bladder
- 200000 Piece / Pieces per Month
- Qingdao seaport
- T/T
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | PLASTSEA |
Product Description
Specifications
Many sizes of bladder for tire curingQuality Guarantee
Delivery Guarantee
Service Guarantee
Tire Curing Bladder
The tire curing bladder is used during the tire vulcanization.
We can supply the tire bladder for PCR tire,OTR tire,TBR tire,Motorcycle tire,etc. Both bias tire and radial tire.
There are different structure and size to meet the different size of tire.
Specification of All steel tire curing bladder | ||||||||||
Bladder code | Diameter Reference Size | Foot LD. dB | Foot height a | Foot width b | Foot gauge to' | Outside Diameter DB | Over-all height HB | Effective periphery LB | Etch page | Applied Tyre |
(in) | (mm) | (mm) | (mm) | (mm) | (mm) | (mm) | (mm) | Section | ||
RB7501 | 16 | 300 | 25.0 | 14.0 | 11.0 | 650 | 370 | 528 | 2 | 7.50R16 |
LL-17 | 16 | 300 | 28.4 | 12.7 | 12.0 | 590 | 414 | 513 | 3 | LT235/85R16 |
LL-16 | 16 | 300 | 28.4 | 12.7 | 12.0 | 635 | 476 | 588 | 3 | 8.25R16 |
RB8251-2 | 20 | 374 | 25.0 | 13.0 | 11.0 | 740 | 376 | 539.6 | 4 | 8.25R20 |
RB9001 | 20 | 380 | 24.0 | 12.0 | 12.5 | 660 | 570 | 650 | 3 | 9.00R20 |
RB10001 | 20 | 380 | 24.0 | 14.0 | 13.0 | 830 | 470 | 670 | 3 | 10.00R20 |
RB12003 | 20 | 380 | 24.0 | 14.0 | 12.0 | 850 | 540 | 744 | 3 | 12.00R20 |
RB14002 | 20 | 372 | 23.5 | 14.0 | 13.5 | 830 | 658 | 860 | 3 | 14.00R20 |
RB315A | 22.5 | 380 | 28.0 | 14.0 | 13.0 | 850 | 590 | 783 | 2 | 315/80R22.5 |
22.5F | 22.5 | 431.8 | 28.6 | 14.3 | 12.7 | 790 | 600 | 754.3 | 3 | 385/65R22.5 |
XL-4 | 22.5 | 384 | 28.4 | 12.0 | 12.7 | 712 | 456 | 576 | 3 | 255/70R22.5 |
B3 | 22.5 | 384.2 | 28.4 | 12.7 | 12.7 | 800 | 550 | 709 | 3 | 295/75R22.5 |
Above parameters are only small parts, if you need other sizes, please tell us for details.
Our bladders are supplied for many famous tyre factories around the world, like Michelin, Bridgestone, Pirelli,etc.
Welcome your requirement for our products.
