1T Single Cage/Cabin SC100 Construction Hoist, Construction Elevator, Construction Lifter, Building Hoist for sale in China
1. Brief Introduction to SC Series of Construction Hoist/Construction Elevator
SINOMAX SC series construction hoist, also called construction elevator, building hoist, are suitable for vertical transport of materials and people widely used in industrial and civil building construction, bridge construction, underground construction, large chimney construction and ship industry etc. It can also be used as permanent or semi-permanent electric elevators in various sites like warehouses and high towers.
1. SINOMAX SC series construction hoist is an elevator driven by gear rack mainly used for transport of materials and people in high building construction. It is easy to install and dismantle and could be rising along with building. SC series construction hoist could be single cage and double cages. Single cage could be changed into double cages after installing one more cage and some parts.
2. Construction hoist with 0-90m high speed frequency inverter could reach 96m/min, adopts mast section 800*800*1508, highly saves much time and improves working efficiency, more stable and reliable.
3. Two kinds of mast section dimension for choice, 650*650*1508mm and 800*800*1508mm. Mast section could be painted or galvanized.
4. Stable performance, reliable safety, easy transportation and strong adaptability,
5.. It can improve working efficiency and reduce workers’ labor intensity.
2. Technical Data of Parameters
Construction Hoist
Model |
SC100 |
SC100/100 |
SC200 |
SC200/200 |
Max Installation Height (m) |
200 |
200 |
200 |
200 |
Rated Loading Capacity (kg) |
1000 |
1000/1000 |
2000 |
2000/2000 |
Rated Lifting Speed (m/min) |
36 |
36 |
36 |
36 |
Rated Passenger Number |
12 |
12/12 |
16 |
16/16 |
Motor Power (kw) |
2*11 |
2*2*11 |
3*11 |
2*3*11 |
Inner Dimension of Cage (m) |
3*1.5*2.2 |
3*1.5*2.2 |
3*1.5*2.2 |
3*1.5*2.2 |
650mm Mast Section Weight (kg) |
124 |
148 |
124 |
148 |
650mm Mast Section Dimension (mm) |
650*650*1508 |
650*650*1508 |
650*650*1508 |
650*650*1508 |
800mm Mast Section Dimension (mm) |
800*800*1508 |
800*800*1508 |
800*800*1508 |
800*800*1508 |
Counterbalance Weight (kg) |
- |
- |
- |
- |
Rated Hanger Lifting Capacity (kg) |
200 |
200 |
200 |
200 |
Construction Hoist with Interver
Model |
SC100P |
SC100/100P |
SC200P |
SC200/200P |
Max Installation Height (m) |
250 |
250 |
250 |
250 |
Rated Loading Capacity (kg) |
1000 |
1000/1000 |
2000 |
2000/2000 |
Rated Lifting Speed (m/min) |
0-58 |
0-58 |
0-58 |
0-58 |
Rated Passenger Number |
12 |
12/12 |
16/16 |
16/16 |
Motor Power (kw) |
2*11 |
2*2*11 |
2*3*18.5 |
2*3*18.5 |
Inner Dimension of Cage (m) |
3*1.5*2.2 |
3*1.5*2.2 |
3*1.5*2.2 |
3*1.5*2.2 |
650mm Mast Section Weight (kg) |
148 |
148 |
148 |
148 |
650mm Mast Section Dimension (mm) |
650*650*1508 |
650*650*1508 |
650*650*1508 |
650*650*1508 |
800mm Mast Section Dimension (mm) |
800*800*1508 |
800*800*1508 |
800*800*1508 |
800*800*1508 |
Counterbalance Weight (kg) |
- |
- |
- |
- |
Rated Hanger Lifting Capacity (kg) |
200 |
200 |
200 |
200 |
