Product Details
Place of Origin: | Shandong, China | Brand Name: | SINOMAX | Model Number: | 20m3, 25m3, 30m3, 40m3 |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
20m3, 25m3, 30m3 40m3 Small Portable Concrete Pump, Mini Mobile Concrete Pump, Trailer mounted Concrete Pump for sale
1 Introduction of SINOMAX Mobile Trailer Concrete Pump
SINOMAX Machinery could manufacture all kinds of concrete pumps such as small models with capacity 20,25, 30,40m3/h, medium models with capacity 40, 50m3/h, large models with capacity 60, 803/h. All the models could be driven by electric motor or diesel engine. It is widely used in pumping mortar, fine stone concrete, normal concrete, high performance concrete in small, medium and large construction projects such as building, tunnel, bridge, high way, hydropower, mining and national defense etc.
2 Features of SINOMAX Mobile Trailer Concrete Pump
1 Compact structure, easily moved, highly movable and flexible
2 Intelligent power control system with PLC for safe, smooth and efficient operation
3 Plunger pump with constant power, ensuring the efficiency of main engine
4 Equipped with wire remote controller, easy to operate
5 High performance sealing of S pipe valve installed with floating wear resistant ring
6 High delivery pressure to meet demand of high building and long distance projects
7 Low cost maintenance, beautiful appearances
3 Technical Parameters of SINOMAX Mobile Trailer Concrete Pump
Technical Data of Small Concrete Pump (Motor)
MODEL | XBS20-08-30 | XBS25-12-33 | XBS30-13-40 | XBS40-13-48 | ||
Max. Theo. Output | m3/h | 20 | 25 | 30 | 40 | |
System | - | Fully Hydraulic Commutation | ||||
Distributing Valve | - | S Pipe Valve | ||||
Max. Outlet Pressure | Mpa | 08 | 12 | 13 | 13 | |
Max. Aggregate Diameter | mm | ≤30 (≤20) | ≤30 (≤20) | ≤30 (≤20) | ≤30 (≤20) | |
Cylinder Diameter * Stroke | mm | DN140*800 | DN140*800 | DN140*1000 | DN140*1000 | |
Power | Kw | 30 | 33 | 40 | 48 | |
Inner Diameter of Delivery Pipeline | mm | 100 (80) | 100 (80) | 100 (80) | 100 (80) | |
Outline Dimension | mm | 4600*1500*1550 | 4600*1500*1550 | 4600*1500*1550 | 4600*1500*1550 | |
Weight | Kg | 2000 | 2000 | 2100 | 2100 | |
Max. Theo. Delivery Distance | Horizontal | m | 350 | 400 | 500 | 600 |
Vertical | m | 120 | 140 | 160 | 180 |
Technical Data of Small Concrete Pump (Diesel Engine)
MODEL | DXBS20-08-56 | DXBS25-12-56 | DXBS30-13-56 | DXBS40-13-56 | ||
Max. Theo. Output | m3/h | 20 | 25 | 30 | 40 | |
System |
| Fully Hydraulic Commutation | ||||
Distributing Valve |
| S Pipe Valve | ||||
Max. Outlet Pressure | Mpa | 08 | 12 | 13 | 13 | |
Discharging Volume of Main Oil Pump | ml/r | 48 | 63 | 80 | 112 | |
Max. Aggregate Diameter | mm | ≤30 (≤20) | ≤30 (≤20) | ≤30 (≤20) | ≤30 (≤20) | |
Cylinder Diameter * Stroke | mm | DN140*1200 | DN140*1200 | DN140*1200 | DN140*1200 | |
Power | Kw | 56 | 56 | 56 | 56 | |
Inner Diameter of Delivery Pipeline | mm | 100 (80) | 100 (80) | 100 (80) | 100 (80) | |
Outline Dimension | mm | 4600*1500*1550 | 4600*1500*1550 | 4600*1500*1550 | 4600*1500*1550 | |
Weight | Kg | 2300 | 2300 | 2450 | 2450 | |
Max. Theo. Delivery Distance | Horizontal | m | 350 | 400 | 500 | 600 |
Vertical | m | 120 | 140 | 160 | 180 |
TERMS OF PAYMENT | 30%TT as prepayment, 70%TT or irrevocable LC at sight before shipment. |
DELIVERY TIME | 10-15 days after receipt of prepayment or irrevocable LC at sight. |
CONTAINER NEEDED | 1*20GP for 1 set, 1*40GP for 2 sets |
SINOMAX Machinery, is a professional manufacturer and exporter specializing in production, R&D, quality control and exporting for nearly 20 years. Belonging to SMG and located in the industrial zone of beautiful coastal city, Qingdao, in Shandong Province, with convenient transportation near to the airport and seaport.
Our products mainly include concrete machinery, construction machinery and materials such as concrete placing boom, concrete boom pump truck, concrete batching plant, concrete mixer, concrete pump, concrete mixer pump, block machine and so on. We have exported to more than 60 countries and regions with excellent quality, such as Southeast Asia, South America, Africa, Oceania and Eastern Europe.
FAQ:
Q: How many kinds of trailer concrete pumps you have?
A: We have all kinds of concrete pumps such as small models with capacity 20,25, 30,40m3/h, medium models with capacity 40, 50m3/h, large models with capacity 60, 803/h.
Q: Do you have concrete placing booms that could be working together with concrete pump?
A: Yes, We have below series.
1: 12/15/18m Manual Mechanical Spider Concrete Placing Booms
2: 13/15/17/18m Mobile Hydraulic Spider Concrete Placing Booms
3: 28/32m Floor Climbing Type and Elevator Well Shaft Climbing Concrete Placing Booms (Tubular Column)
4: 21/24/28/32 Elevator Well Shaft Climbing Concrete Placing Booms (Mast Section)
Q: What is the configuration?
A: For exporting, most of the components are world famous top brands such as VOLVO, DEUTZ, Siemens, Rexroth, Kawasaki, Schneider, Omron, LG, Eaton, Manuli, Parker etc. The configuration could be customized according to client’s requirements.
Q: Is engineer available for training and after sales service?
A: Yes, our oversea engineers team are standing by for oversea service. Some engineers could speak English.
