Help CenterCE UL SY-CNC-80 10 Set Free Dies Hydraulic Hose Crimping Machine Price
Related Products
-
CE UL SY-CNC-80 Computer Control CE ISO 1/8''-2'' 10sets Free Mould 220V/230/415/308V High-pressure Hoses Press MachineUS$ 3,500 - 4,800MOQ: 1 Set -
CE UL SY-CNC-80 Computer Control Hydraulic High Pressure Hose Pressing Machine PriceUS$ 3,280 - 4,690MOQ: 1 Set
-
Touch Screen Digital Control SY-CNC-80 Middle Pressure Hydraulic Hoses Crimping MachineUS$ 3,280 - 4,690MOQ: 1 Set
-
Touch Screen Digital Control SY-CNC-80 Hydraulic Hose Crimping Machine 2inch 4SP, R13US$ 3,280 - 4,690MOQ: 1 Set
-
Hydraulic Hose Crimping Machine ItalyUS$ 3,500 - 4,800MOQ: 1 Set
Digital control hose crimping machine
Model | SY-80 |
Warranty | 3 years |
Crimping range: Inner | 4--32mm(4/25”--1 1/4”) |
Outer | 6--80mm(1/4”--3 1/4”) |
Max. opening | 120mm |
Crimping force | 6000KN(600T) |
Dies sets | 14 sets |
Matching power source | 220V/380V |
Matching power | 3KW/4KW |
Noise Level | 68dB |
Operation mode | Automatic |
System pressure | 31.5mpa |
Overall dimension | 600(L)*480(W) *600(H)mm |
mold opening and closing | ±40mm |
Mold length | 65mm |
Grade number of hydraulic oil | 46/32# |
Mold opening time | 1.2s |
Closing time | 4s |
Mold NO. | ∅6 | ∅8 | ∅10 | ∅13 | ∅16 | ∅19 | ∅25 | ∅32 | ∅38 | ∅51 |
Crimping range | 15-25mm | 18-28mm | 20-30mm | 23-33mm | 26-36mm | 29-39mm | 37-47mm | 46-56mm | 51-61mm | 63-73mm |
Mold lengths | 65mm | 65mm | 65mm | 65mm | 65mm | 65mm | 80mm | 80mm | 80mm | 80mm |
Application of our hydraulic hose crimping machine:
Our products are widely used in
Engineering machinery,Agricultural machinery,Vehicle repair service,Oil field,Hydraopost,Steel wire rope,Hydraulic machines,Greenhouse tubes.
Standard export package:Inner PVC bags and outer fumigation wooden cases.
