Specifications
1. LCD TV motherboard2. Full function
3. Match MS6M20 board can support 3D screen
4. USD support multi-media
LCD TV motherboard with 59 solution HDVX9-AM-V59
1.This tv board is suitable for worldwide analog TV system PAL/NTST/SECAM,which is compatible with LCD panel mainstream manufacturers,such as SAMSUNG, CMO, AU, LGP,SHARP,BOE etc
2.It can reappear real world image color and sound
3.Main IC adopts MSTAR single chip TSUMV59XU program
4.Standard type Can be extended plate type and L type
5.TV system support PAL+SECAM/NTSC system, optional full standard system
6.Max supports FULL HD 1920X1080 resolution TFT-LCD screen
7.Match MS6M30 can support polarization/shutter 3D screen
8.Many selection according to the design, support 2XAV input,1XVGA port,support 1920X1080@60Hz input,
9.One analog HD port signal(YPbPr)input, max support 1080p format, can expand two road
10.1XHDMI 1.3A, HDCP1.2 and DVI 1.0
11.1XUSD port,suports Audio(MP3,WMA),Video(AVI,RM,RMVB MPEG1~4),image(JPEG,BMP,PNG),text file(TXT)
12.Dynamically adjust picture's color , contrast ratio, definition and so on
13.Brightness, chroma instantaneous improvement function , black / white level extensions function , color compensation function
14.3D video decoding(PAL/NTSC), brightness separation, spatial noise reduction function
15.Supports control of treble or bass ,Stereo input.
16.Rating of Audio loudspeaker output is10W*2(8ohm)
17.Automatically detect input video format
18.Imitation WINDOWS XP interface OSD ,Humanization operating menu.
19.Reliable EMC and treatment measure of anti-static.
20.Built-in large power input optional
