Product Name: 21.5" 1920*1080 Pen Input OSD Open Frame LCD Touch-Screen Display
Model No.: CND-A215PM-NI
Key Features:
1. Touch Technology: Electromagnetic Passive Resonance
2. 2048 level Pressure Sensitivity;
3. 1080P Full HD Display Screen;
4. Vedio Interface: HDMI + DVI + VGA;
5. Narrow-sided Full Flat Screen Solution;
6. Multi-angle Adustable Bracket;
7. Side Cable Outlet, More Convenient.
8. Optional Function: Anti-peeping, Wireless Passive Electromagnetic Pen, Self-destruction, light sensor, Explosion Proof, Water-Proof, Anti-dust.
Open Display Product Speceification
| Panel Specification | |
| Panel Size | 21.5inch |
| Panel Type | TFT-LCD |
| Display Ratio | 16:09 |
| Active Area | 475.64mmx268.11mm |
| Resolution | 1920 x 1080 |
| Piexl Pitch | 0.248mm x 0.248mm |
| Brightness (TYP) | 250cd/m2 |
| Color | 16.7M Colors |
| Response Time | 5ms |
| Viewing Angle | Horizontal 170°, Vertical 160° |
| Touch Specification | |
| Touch Technology | Passive Electromagnetic Resonance |
| Pressure Sensitivity Level | 2048 |
| Report Rate | 200pps |
| Accuracy | +/-1.5mm (Center), +/-2mm(Edge) |
| Tilt Angle | +/- 45° from Vertical |
| Sensor Height | 5-15mm |
| Interface | USB 2.0 |
| OS Support | WinXP / Vista / Win7 / Win8 / Mac OS |
| Pen Specification | |
| Type | Wireless Passive Electromagnetic Pen |
| Press Key | Upper Key |
| Pen Tip | Switch Freely |
| Weight | 20g |
| Power Specification | |
| Voltage | 110V~220V |
| Power Type | External DC Power Adapter |
| Output Voltage/Current | 12V/3A |
| Power Consumption | 30W |
| Interface Specification | |
| Power | DC Jack |
| Touch Control | USB 2.0 |
| Video Input | VGA*1 + HDMI*1 + DVI*1 |
| Operation Control | |
| OSD Language | Chinese/English, 9 Languages |
| OSD Menu | Power On/Off, Up/Down, Menu, Auto |
| Others | |
| Dimension | 538mm x 318mm x 40mm |
| N.W. | 3.8KG |
| G.W. | 4.3KG |
| Working Temperature | 0-50℃ |
| Working Humidity | 5-90% |
| Storage Temperature | -20~+60℃ |
| Storage Humidity | 5-90% |
OF Touch Screen Monitor Gerneral Description
Open Frame Touch Screen Monitor, for Short OF, Mainly used for ATM, VTM, Kiosk, HMI, Game Machine, etc;
Size: 8.4”,10.4” , 15”,17”,19”,21.5”,22”
Hardware of Open Frame Touch Screen Monitor is much similar to common touch screen, OF is more flexible, Here are some application,
1. Open Frame Material is as follows:
1-1: Metal Enclosure
Application: order quantity no more than 1K, no need Mould, but not suitable for PCT and Multi-touch screen.
1-2: Plastic Enclosure
Application: order quantity more than 1K, or open-mould is acceptable to customer; good-looking, stable, lowering cost, suitable for various kinds of Touch Screen, especially PCT Touch Screen is only suitable for Plastic Enclosure.
1-3: Metal Enclosure +Flat PCT Touch Screen Monitor: Touch Screen itself can act as OF front Enclosure when OF with Flat Touch Screen is required
2. OF Can use Restive Screen, SAW Screen, IR Screen, SCT, multi-touch (double-touch) Capacitive PCT, Flat PCT; and the structure and size of OF are mostly Customized (OEM).
3. A/D board of OF is same as Desk-top Touch Screen Monitor
3-1: Open frame touch-screen monitor: Projection Flat Capacitive Touch-screen panel: Technology Advantage: PCT Multi-touch, Flat Pane (IP65), Explosion Proof, Anti-dust, Water-proof, Anti-peeping, Light Sensor, Electromagnetic hand writing, VESA75 &100, Flexible Installation( In-wall), VGA+DVI, USB Touch, Support OS Win8
Product Size: 15”, 17”, 19”, 21.5”
3-2: Technology Advantage: 5 wire Resistive touch panel, SAW touch-panel, IR touch-panel; Explosion Proof, Anti-dust, Water-proof, Anti-peeping, Light Sensor, Electromagnetic hand writing, VESA75 & 100, Flexible Installation; VGA+DVI, USB Touch, Support Win8
Product Size: 8.4”,10.4” , 15”,17”,19”,21.5”,22”
Open Frame Display Serial:
Touch Panel Solutions Provide Whole-serial Comercial & Industrial Display, including industrial grade LCD Panel, Open Frame Display, and Outdoor Display, with Projection Capacitive Touch Technology, meet all application requirements. Besides, we've Focused on Industrial LCD Display Technology, and developed Auto-adustment technology, pen input, Explosion Proof, Anti-peeping etc. which bring more Additional Value to Industrial display.
| Indutial Integrated Display Serial Products | |||||
| 10.4 Inch | 15 Inch | 17 Inch | 19 Inch | 21.5 Inch | |
| Panel Ratio | 4:03 | 4:03 | 4:03 | 4:03 | 19:09 |
| Resolution | 800*600 | 1024*768 | 1280*1024 | 1280*1024 | 1920*1080 |
| Active Area(mm) | 212.5x159.5 | 306x229.5 | 339.5x272 | 377.3x302 | 476.6x268.1 |
| Brightness | 400 | 400 | 350 | 350 | 200 |
| Contrast Ratio | 400:1 | 400:1 | 1000:1 | 1000:1 | 1000:1 |
| Backlight | LED | CCFL/LED | LED | LED | LED |
| Display Color | 16.2M | 16.2M | 16.2M | 16.2M | 16.2M |
| Viewing Angle(H/V) | 130°/140° | 160°/160° | 160°/160° | 160°/160° | 170°/160° |
| Life Time (Hours) | 50000 | 90000 | 90000 | 90000 | 90000 |
| Whole Plane Projection Capacitor | Yes | Yes | Yes | Yes | Yes |
| Conventional Projection Capacitor | Yes | Yes | Yes | Yes | Yes |
| Conventional Surface Capacitor | Yes | Yes | Yes | Yes | Yes |
| Explosion Property | Yes | Yes | Yes | Yes | Yes |
| Pen Input | Yes | Yes | Yes | Yes | Yes |
| Light Sensor | Yes | Yes | Yes | Yes | Yes |
| Operation Systyem | Windows XP / Vista / Win7 / Win8 /32 & 64, Mac OS | ||||
| I/O Interface | Touch Control: 1xUSB; 1xSerial Port(RJ45 Convert to RS232) | ||||
| Installation | Signal Input: VGAx1, DVIx1 | ||||
| Working Enviroment | Temperature: 0-55℃; Humidity: 20~85% | ||||
| Storage Enviroment | Temperature: -10~60℃; Humidity: 10~90% | ||||
CND RD Team
Quality Assurance
Workshop and equipments
CND Partners
CND Certificates: ISO, Patent, Hi-Tech
is the best choice for LCD/LED main board and Integrated Display solutions, with over 10 years professional experiences both in hardware and software design, she has gained very good reputation during cooperation with biggest clients from financial , rail transit, and industrial etc. choose CND, choose a mutual win-win partner.
