Product Name: 10.1" Anti-dust Water-Proof,Explosion-Proof Self-destruction anti-peeping pen-input Open Frame LCD Touch-Screen Monitor
Model No.: CND-A101PM-NIMI
Open Display Product Speceification
OF Touch Screen Monitor Gerneral Description
Open Frame Touch Screen Monitor, for Short OF, Mainly used for ATM, VTM, Kiosk, HMI, Game Machine, etc;
Size: 8.4”,10.4” , 15”,17”,19”,21.5”,22”
Hardware of Open Frame Touch Screen Monitor is much similar to common touch screen, OF is more flexible, Here are some application,
1. Open Frame Material is as follows:
1-1: Metal Enclosure
Application: order quantity no more than 1K, no need Mould, but not suitable for PCT and Multi-touch screen.
1-2: Plastic Enclosure
Application: order quantity more than 1K, or open-mould is acceptable to customer; good-looking, stable, lowering cost, suitable for various kinds of Touch Screen, especially PCT Touch Screen is only suitable for Plastic Enclosure.
1-3: Metal Enclosure +Flat PCT Touch Screen Monitor: Touch Screen itself can act as OF front Enclosure when OF with Flat Touch Screen is required
2. OF Can use Restive Screen, SAW Screen, IR Screen, SCT, multi-touch (double-touch) Capacitive PCT, Flat PCT; and the structure and size of OF are mostly Customized (OEM).
3. A/D board of OF is same as Desk-top Touch Screen Monitor
3-1: Open frame touch-screen monitor: Projection Flat Capacitive Touch-screen panel: Technology Advantage: PCT Multi-touch, Flat Pane (IP65), Explosion Proof, Anti-dust, Water-proof, Anti-peeping, Light Sensor, Electromagnetic hand writing, VESA75 &100, Flexible Installation( In-wall), VGA+DVI, USB Touch, Support OS Win8
Product Size: 15”, 17”, 19”, 21.5”
3-2: Technology Advantage: 5 wire Resistive touch panel, SAW touch-panel, IR touch-panel; Explosion Proof, Anti-dust, Water-proof, Anti-peeping, Light Sensor, Electromagnetic hand writing, VESA75 & 100, Flexible Installation; VGA+DVI, USB Touch, Support Win8
Product Size: 8.4”,10.4” , 15”,17”,19”,21.5”,22”
| IndutialIntegrated Display Serial Products | |||||
| 10.4 Inch | 15 Inch | 17 Inch | 19 Inch | 21.5 Inch | |
| Panel Ratio | 4:03 | 4:03 | 4:03 | 4:03 | 19:09 |
| Resolution | 800*600 | 1024*768 | 1280*1024 | 1280*1024 | 1920*1080 |
| Active Area(mm) | 212.5x159.5 | 306x229.5 | 339.5x272 | 377.3x302 | 476.6x268.1 |
| Brightness | 400 | 400 | 350 | 350 | 200 |
| Contrast Ratio | 400:1 | 400:1 | 1000:1 | 1000:1 | 1000:1 |
| Backlight | LED | CCFL/LED | LED | LED | LED |
| Display Color | 16.2M | 16.2M | 16.2M | 16.2M | 16.2M |
| Viewing Angle(H/V) | 130°/140° | 160°/160° | 160°/160° | 160°/160° | 170°/160° |
| Life Time (Hours) | 50000 | 90000 | 90000 | 90000 | 90000 |
| Whole Plane Projection Capacitor | Yes | Yes | Yes | Yes | Yes |
| Conventional Projection Capacitor | Yes | Yes | Yes | Yes | Yes |
| Conventional Surface Capacitor | Yes | Yes | Yes | Yes | Yes |
| Explosion Property | Yes | Yes | Yes | Yes | Yes |
| Pen Input | Yes | Yes | Yes | Yes | Yes |
| Light Sensor | Yes | Yes | Yes | Yes | Yes |
| Operation Systyem | Windows XP / Vista / Win7 / Win8 /32 & 64, Mac OS | ||||
| I/O Interface | Touch Control: 1xUSB; 1xSerial Port(RJ45 Convert to RS232) | ||||
| Installation | Signal Input: VGAx1, DVIx1 | ||||
| Working Enviroment | Temperature: 0-55℃; Humidity: 20~85% | ||||
| Storage Enviroment | Temperature: -10~60℃; Humidity: 10~90% | ||||
1. Established in 2006, Located in ShenZhen, Over ten years experiences manufacturing.
2. Main products: Main board solutions for LED/LCD monitors, TV, which applied in Computer, advertising, Vehicle, industrial, hospital, Financial industries, home appliance.
3. One-stop solution, save your costs & times;
4. With Strong R&D team, provide you professional technique supports and good service
5. OEM/ODM and small/large orders are welcome;
6. High quality, On-time delivery, safe shipment, and excellent after-sale service.
7. In China, the biggest customers CRRC Corporation Limited, and Financial industrial such as ABC, BOC, CBC, etc.
CND RD Team
Quality Assurance
Workshop and equipments
CND Partners
CND Certificates: ISO, Patent, Hi-Tech
is the best choice for LCD/LED main board solutions, and Industrial Monitor Solution for ATM, VTM, HMI, Kiosk, etc. with over 10 years professional experiences both in hardware and software design, she has gained very good reputation during cooperation with biggest clients from financial , rail transit, and industrial etc. choose CND, choose a mutual win-win partner.
