ULS-200 High Resolution Ultrasonic Diesel Tank Level Sensor for Gps Tracking System RS232 /485 and 0-5v Output

Overview Of Sensor

This Product is adopted by non-contact measurement of ultrasonic sensor technology, which is researched and developed by our company and it is initiated in China. It is also widely used in fuel consumption project and all products were sold abroad.

Technical Parameters

Features Of  diesel tank level sensor

1. High accuracy.

Resolution of sensor’s measurement for fuel height is 0.1mm.And its measurement accuracy is ±0.5%. It keeps higher accuracy even in highest or coldest outside environment.

2. Excellent stability.

Different from direct-contact measurement of float-type, pressure-type, magnetic sliding-type, fuel level sensor uses ultrasonic and non-contact measurement, which can avoid pollution and corrosion from fuel and keep stability in a long period of time.

3. Easy installment and maintenance.
You only need to install the sensor probe on lower surface of fuel tank. You don’t need to change its original measurement system or punch hole for it. Its original fuel meter operates as usual.

4. No pollution and lower consumption.
This non-contact measurement and non-punch hole for fuel tank can keep off pollution from fuel.

5. High reliability.
It can still work in bad environment and it is damp-proof, acid-proof, flame-retardant, anti-interference, intellectualized. This product can be used independently to check data from auxiliary display. It can also use with GPS, which sends data to background for statistics, analysisand query.

Installation of ultrasonic sensor

LED light notification

LED1:probe indicator

slow flash of green:normal

slow flash of red:abnormal

LED2:power indicator

slow flash of green:normal

slow flash of red:analog voltage output abnormal(contact with service people)

light not working:power abnormal(check power supply)
