100W Single Arm Pole PWM Controller LED Solar Street Lamp
Details:
1.Solar Panel : Power:2pcs 180W, poly crystalline silicon module
2.Battery: 2PCS 12V 200AH
3.PWM Controller:12V/30A
4.Working Duration: start to work from Dusk to Dawn; keep 8hours working throughout 3days,in rainy or cloudy days
5.Lamp:Diameter of lamp post: 55mm; Lamp body Dimension: 680(L)*320(W)*160(H); IP Rating: IP67
6. Working Temperature: -30°C ~+60°C
Main Features of Lamp:
1. Power:120W
2. LED Chip: Bridgelux or Epistar
3. Input Voltage: AC85~265V or DC12V
4. Power Factor: >0.95
5. Power Efficiency: >0.86
6. Protection Level: IP67
7. Certificate: CE / ROHS / IEC
8. Beam angle:120°
9. Lifespan: 30000-50000hours
10. Luminous Efficacy: 90LM/W, 100LM/W, 110LM/W
11. Color Temperature:Pure white 5500-6000K,warm white 3000-3500K,daylight 4000-4500K
| Specifications:LED Street light | |||||
| Model | SEM-R30-01S | SEM-R60-01S | SEM-R80-01S | SEM-R100-01S | |
| LED light power | 30W | 60W | 80W | 120W | |
| Luminous efficiency | 90lm/w 100lm/w 110lm/w are available | ||||
| Color temperature | Pure white: 5500-6000K,warm white: 3000-3500K,daylight: 4000-4500K | ||||
| Diameter of lamp post: | 60mm | ||||
| LED lifespan | 30,000-50,000hours | ||||
| System voltage | AC85-265V or DC12V | ||||
| Working temperature | -30 °C ~+60 °C | ||||
| Wind resistence | 130KM/H | ||||
| IP rating | IP67 | ||||
| Certificates | CE, ROHS,IEC | ||||
| Packing | poles wrapped with flax, other components packed in cartons | ||||
| Departure port | SHENZHEN | ||||
| Availability | 30W-120W Solar street light available | ||||
Advantage:
1.Energy saving,No UV or IR radiation,No flickering,No pollution to the environment
2.No bad glare, stroboscope or startup delay, eliminating the disadvantage of the traditional street light.
3.It uses solar battery, which is made of high quality, efficient sillicon solar wafers and tempered glass to supply power.
Photos:
Product Chart And IES Report:
Models:
we can make LED solar street light from 30W to 120W
Hot sale series:30W 60W 80W 100W 120W
LED Street Light Series:
Application:
Garden lighting Industrial park lighting Sidewalk lighting Residential road
lighting.
Certification:
About Us:
Trade Term:
1.Price term: EXW; FOB ShenZhen Base on order value USD15000 per lot
2.Payment term : 30% deposit, Balance before shipment
3.Delivery time : Samples in 4days, larger orders in 7-15days after payment
4.Shipment way: TNT, UPS ,DHL , FEDEX, EMS or by air or by sea
5.The price don't include tax &shipping freight and the price is valid for a week
6. Return policy: we can repair or replace defective goods in next order within three years
Our service:
1.Your inquiry related to our products and prices will be replied in 24 hours.
2.Well-trained and experienced staffs to answer all your inquriy in fluent English.
3.OEM,and your customized lightings we can help you to design and put into product.
4 Update quotation monthly
5.Protection of your sales area, ideas of design and all your private information.
