Help CenterHot Melt Glue Machine
Related Products
Specifications
1.samll and light,space-saving,convient for mobile work2.Spot spraying, strip spraying, Mist spraying or scraper nozzle gluing
l FEATURES:
1.The melting tank increases the area for spreading heat and improve the melting rate.
2.Applicator temperature is exactly controlled by electronic P.I.D numeric controller to avoid carbonization inside the tank.
3.can choose the gear pump or piston pump to increase the use of the machine
4. Modularizing design helps to change various size gear pump(piston pump) or handle the return valve easily.
5. Filters are installed inside manifold and dispensing nozzle, reducing maintenance and glue path block.
6. Apply to automatic packaging, life paper.and shoes-making.
7.Application for strip,spiral spray and slop gun.
l SPECIFICATION:
ITEM |
UNIT |
YT-MD502 |
YT-MD501 |
YT-QB502 |
YT-QB501 |
Tank Capacity |
Liter |
5.0 |
5.0 |
5. 0 |
5.0 |
Max. malting rate |
KGHOUR |
7.0 |
7.0 |
7.0 |
7.0 |
Max. Operation temp. |
°C |
200 |
200 |
200 |
200 |
Melt Power |
Watt |
2200 |
2200 |
2200 |
2200 |
Motor power |
Watt |
90 |
90 |
|
|
Air pressure |
KGCM² |
4-6 |
4-6 |
4-6 |
4-6 |
Demension(L*W*H) |
MM |
420*380*640 |
420*380*640 |
420*380*640 |
420*380*640 |
Weigh |
KG |
35 |
35 |
35 |
35 |
Max. Viscosity |
CPS |
30,000 |
30,000 |
25,000 |
25,000 |
Power Requirement |
Single Phase (1Φ), 220 V |
||||
Hose Output |
Line |
2 |
1 |
2 |
1 |
Pump Type |
|
Gear pump |
Gear pump |
Piston pump |
Piston pump |
