Help CenterApplicators for Mattress
Related Products
Specifications
1.Modularizing design,nvinent for maintenace.
3.hot melt glue machine .
FEATURES:
1.Applicator temperature is exactly controlled by electronic P.I.D numeric controller to avoid carbonization inside the tank.
2.Open tank to better protect security, add hot melt adhesive at any time.
3. The gear pump independent suspension system,convinent for maintenace.
4.Gear pump and piston pump for requirement. The precise flow control valves.
5. Modularizing design helps to change various size gear pump or handle the return valve easily.
6. Multi-layer stainless steel filter net can effectively filter the impure matter and prolong the machine life.
SPECIFICATION:
ITEM |
UNIT |
YT-M10P4 |
YT-M10P3 |
YT-M10P2 |
YT-Q10P3 |
Tank Capacity |
KG |
12.0 |
12.0 |
12.0 |
12.0 |
Max.malting rate |
KGHOUR |
18.0 |
18.0 |
18.0 |
18.0 |
Max.Operation temp. |
°C |
200 |
200 |
200 |
200 |
Melt Power |
Watt |
3200 |
3200 |
3200 |
3200 |
Motor Power |
Watt |
200 |
200 |
200 |
|
Demension(L*W*H) |
MM |
650*430*440 |
650*430*440 |
650*430*440 |
|
Weigh |
KG |
48 |
48 |
48 |
40 |
Max. Viscosity |
Cps |
100,000 |
100,000 |
100.000 |
120,000 |
Hose Output |
Line |
4 |
3 |
2 |
1-3 |
Power Requirement |
Single Phase (1Φ), 220 V |
||||
Pump Type |
|
Gear pump |
Gear pump |
Gear pump |
Piston pump |
