Level and Cut to Length Roll Forming Machinery
- XINGANG TIANJIN
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Steel Coil Straightening an Cutting and Straightener Machine
-
Cut to Length Steel Coil to Sheets Machine
-
Dixin Hot Sale Full-automatic High Speed Steel Coil Cut to Length Line
-
DX 1250mm Steel Sheet Flattening and Cutting Machine
-
Dixin Flat Plate Rolling Machine From China
-
Dixin Metal Sheet Uncoiler and Cut at Certain Length Machine
Product Details
| Place of Origin | Hebei, China | Brand Name | DIXIN | |
| Model Number | DX-1250 | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Level and cut to length roll forming machinery
Technical parameter
1. Specification parameters:
a. Applied to: cold-rolled steel, color plates, tinning plates and so on;
b. Quality of material: High quality steel of China or the international standard steel;
c. Tensile strength: δb≤450Mpa,δS≤260Mpa;
d. Thickness: 0.3-3 mm;
e. Width: 1500mm(Max);
f. Coil I.D: φ508;
g. Coil O.D: φ1500mm(Max);
h. Capacity: 10T(Max);
i. Knife pivot diameter of slitting: φ180;
j. Slitting blade: φ180Xφ320X15;
k. Material of slitting blade: 6CrW2Si.
2. Finished parameter:
a. Width precision: ≤±0.05mm
3. Other parameters:
a. Power: 380V/50Hz/3Ph;
b. Line speed: 0-120m/min;
c. Total power: 140Kw;
d. Dimension: 25m (L)X6m(W);
e. Operator needed: 1 technician and 2 general workers;
f. Production orientation: from left to right(the operation table face the machines).
2. Main workflow
| main machine: | ||||||
| 1. Coil car | ||||||
| 2. Decoiler | ||||||
| 3. Peeler table | ||||||
| 4. Precision leveler | ||||||
| 5. Loop Bridge | ||||||
| 6. Side Guide Roller | ||||||
| 7. Servo feeder | ||||||
| 8. Rotary shear Machine | ||||||
| 9. Conveyor table | ||||||
| 10. Stacking table | ||||||
| 12. Lifting table | ||||||
| 13. Hydraulic Systems | ||||||
| 14. Pneumatic Systems | ||||||
| 15. Electrical System PLC Control |
The pictures of cut to length line for Galvanized steel/stainless steel/color steel coil
