XT Diode Pump Laser marking machine for all materials products are detailed as follow:
Equipment Features:
1. Adopts famous-brand semi-conductor module, beam quality good, and laser power is stabile, life time over 10k hours.
2. Sharp laser beam, high speed and precise marking, beam stable and reliable, low processing costs.
3. Software: with red preview, mirror marking, graphical alignment, hierarchical set parameters functions.
4. With professional constant temperature water cooling system, 24-hour continuous working is reliable. Be applicable to production lines.
5. Rotary worktable system is optional, thus, accomplish marking on cambered surface.
6. Under WINDOWS interface, compatible with files outputted from software such as CORELDRAW, AUTOCAD, PHOTOSHOP etc. Support PLT, AI, DXF, BMP and other documents, directly using SHX, TTF font.
Application Industry:
Materials: mainly for metals, oxides and alloys, ABS, epoxy resin, ink etc.
Fields: electronic components, electrical appliances, jewellery, glasses, hardware, auto parts, telecommunications products, plastic buttons, IC etc.
Technical parameters
Laser power: |
50W or 75w |
Laser wavelengths: |
1064 nm |
Working area: |
100x100mm, 160x160mm,200x200mm (optional) |
Marking speed: |
≤ 7000mm/s |
Min. characters: |
0.2 mm |
Repeated precision: |
± 0.003mm |
Power Consumption: |
≤ 2.8KW |
Power supply: |
220V/50HZ 15A |
G.W.: |
280KGS |
Dimension: |
Optic system: 1200×380×1250mm Control system : 560×610×830mm Cooling system : 610×430×720mm |
Sample Picture:
P1:
P2:
p3:
