portable vin number marking machine

FOB Price

USD $4,000 - $8,000 / Set

1 Set(Min.Order)

Supply Ability 500 Set / Sets per Month
Port Qingdao
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Condition:	New	Laser Type:	Fiber Laser	CNC or Not:	Yes
Cooling Mode:	Air Cooling	Control Software:	EZCAD	Graphic Format Supported:	AI, BMP, DST, DWG, DXF, DXP, LAS
Working Accuracy:	0.01mm	Place of Origin:	Shandong, China	Brand Name:	XT LASER
Model Number:	XTL-F30	Power(W):	30W	Certification:	CE, ISO, SGS
After-sales Service Provided:	Engineers available to service machinery overseas

Packaging Details

wooden case for portable vin number marking machine

Product Description

portable vin number marking machine

Standard Model :

Including Control Box ,Lifting worktabke with laser head ,Laptop .This machine is very compact and can put on the desk for marking works.package size : 850x480x850mm ,Gross weight: 95 kgs . Transporaton : By Sea or Airline .

Features:

1.Marking high precision spare parts , such as Gold, Silver, Jewelry, Electronic spare parts etc.

2. High speed marking speed and perfect marking effects.

3.Working time : 200,000 hours(USA model) don't need change any consumptive materials .4.CE certificates 5.Compact designing .

6.Min marking letter : 0.15mm 7.Max .Marking depth :1.5-2.0mm (hard steel )

Delivery Time:1 week/ Transportation: BY SEA ,AIRLINE

Application & Materials:

This type laser marker suitable for Gold, Silver, Diamond, Sanitary Equipments, Foods Packing, Tobacco Label, Beer label, Drink Label, Medicine Packing, Medical Equipments, Glasses and Clock, Auto Parts,Plastic& Paper Materials, The Electron, Hardware which with high request for depth, smooth,accuracy such as horologe, Mould, bitmap marking etc.

Laser Power: 10W, 20W, 30W, 50W

Technical Parameters:

Laser Source	Fiber Laser
Output Power	50W30W/20w/ 10w
Wavelength	1060nm
Beam Quality	<2
Repeat Frequency	10khz--- 100khz
Pulse Energy	2mJ
Beam Divergence	-0.3 to +0.3mrad
Laser Class	IV
Resolution	18μ
Repeatablility	50μ
Marking Scope	110mmx 110mm/ 175mmx 175mm (optional)
Linear Speed	800 character/ s
Marking Linear Speed	≤12,000mm/s
Marking Depth	Max. 1.0- 1.5mm (hard steel)
Min. Line Width	0.012mm
Min. Character Size	0.15mm
Repeat Accuracy	±0.003mm
Input Power	0.5kw
Electrical Source	220v/50hz or 60hz

1. The video of Marking white color on anodized aluminium

https://youtu.be/Xw1uwwcvdoc

2. The video of marking black color on stainless steel

https://youtu.be/HKJJe5hI1Lk

3. marking white color on stainless steel

https://youtu.be/fWpqehTSbVI

4. mini fiber laser machine marked black color on surgical instruments:

https://youtu.be/y6YwWrJWfEg

5. LED lamp marking machine fiber laser marking machine for led mark

HTTP://youtu.be/ZhcBsIWjaB0

6.Ear tag marking

https://youtu.be/Nyn1Wl66v8Q

7. bird ring laser marking machine

https://youtu.be/QlwnmKphhaQ

Our Services

1. 24/7 service is available to each customer. And if any technical questions or problems, our engineers will help you and give you solutions on the phone or by face-to-face communication online.
2. One-year warranty is provided. (The detailed reference will be written into the final contract.)
3. Professional staff for installation and training if needed.
4. Spare parts are supplying on time or doing some inventory if promising certain sales volume.
5. Faster delivery, we will support our sole agent to do the stock if good sales, then more convenient and helpful.
6. If the sales are good, we will arrange some famous exhibition fairs in the local or surroundings, and give our full support to our agents at the fair. We will provide our sample machines, catalog, DVD, manuals, etc. All native customers belong to our local agent, which is our basic rule. And we promise the final delivery is the same as displayed prototype.

Trade Terms:

1. Payment: T/T, Western Union, MoneyGram,PayPal; 30% deposits; 70% balance before deliverying.

2. Delivery Time: 3-5 days afterpayment will send Jinan XTLASER cheap metal 10w optical fiber laser marking machine price

3. MOQ: 1set Jinan XTLASER cheap metal 10w optical fiber laser marking machine price1

4. Package Informations: normally use wooden box to pack Jinan XTLASER cheap metal 10w optical fiber laser marking machine price
