Production date online fly laser marking machine for medicine paper/packing boxes is one of our company fast moving marking machines.
PRODUCT DETAILS
Production date online fly laser marking machine for medicine paper/packing boxes are detailed as follow:
Good quality! Lowest price!! Best service!!!
Equipment Features:
1.General machine, adopted back focalization, laser power is controlled by the software and serially adjustable.It is applicable to fine marking on nonmetal materials with low requirements.
2.Adopting CO2 RF laser tube which has excellent performance and long life<20k hours>.
3.Adopting high-speed galvanometer system with high speed, high precision and stable performance.
4.Adopting imported optics lens, low loss, excellent focalization performance.
5.The marking software is mightiness ,under WINDOWS interface, compatible with CORELDRAW, AUTOCAD, PHOTOSHOP etc. a variety of software output files. Support PLT, AI, DXF, BMP and other documents, directly using SHX, TTF font. Support automated coding, serial number, batch number, date, bar code and two-dimensional code marking.
Specification:
Laser wavelength: 10.6um
Laser power: 30w
Using lift: 20k hours
Mark linewidth: 0.15mm
Marking field: 50*50, 70*70, 100*100 ,140*140
Marking speed :7000mm/s
Minimum character : 0.4mm
Repeating orientation precision : +0.01mm
Cooling style : air cooling
Average power consumption : ≤0.6kw
Power supply : 220V/50HZ 10A
Humidity of the environment: 5% to 75% (no condensation)
Working environment : smoothly in a clean environment without vibrating or dirt in the air.
Application:
Materials: Majority of nonmetal materials such as leather, cloth, wood, bamboo, paper, organic materials, plastic, epoxy resin etc.
Application Industry: Electronic components, medicines, food, drinking package, leather products, rag trade, woodworks, craftworks and package.
Parameter:
Laser Wavelength |
10.6um |
Laser Type |
CO2 RF glass tube |
Laser Power |
30W/50W/100W/10W |
Machine Power |
1KW |
Marking Area |
200*200mm(optional) |
Resolution Ratio |
0.025mm |
Marking Speed |
7000 mm/s |
Engraving Depth |
≤1 mm(depends on the Materials) |
Minimum Linewidth |
0.015mm |
Minimum Character |
0.2mm |
Repeatability Precision |
±0.005mm |
Power Supply |
220V |
Applied Material
It is used for nonmetal surface laser marking,such as ceramics,synthetic material,rubber,leather,paper products.
Applied Industry
1. For regular leather goods and apparel industry
2. For leather engraved designs,marking on agriculture products
3.Rubber ,soft plastic and so on non-metal materials.
Marking machine photo:
Marking photos
COMPANY PROFILE
Jinan Xintian Technology Co.,Ltd is professional manufacturer of laser equipment, established in 2004.
It is a professional manufacturer engaged in the research,development, production and service of
Diode pumped Laser marking machine, Fiber laser marking machine,CO2 laser marking machine,Pneumatic marking machine,Laser engraving machine,Laser welding machine, Laser cutting machine and Laser trimming machine.
Attend the exhibition
CERTIFICATE
Production date online fly laser marking machine for medicine paper/packing boxes has passed the CE certificate and ISO9001:2008.
NAMECARD
OTHER PRODUCTS:
Except Production date online fly laser marking machine for medicine paper/packing boxes we have other models for your check:
Fiber laser marking machine,pneumatic marking machine,Semi-conductor side pumped laser marking machine
