Heavy Duty Prop
Min. |
Max. |
Internal Tube |
External Tube |
1.8M |
3.2M |
48mm*2.0mm |
60mm*2.0mm |
2.1M |
3.4M |
48mm*2.0mm |
60mm*2.0mm |
2.2M |
4.0M |
48mm*2.0mm |
60mm*2.0mm |
2.4M |
3.9M |
48mm*2.0mm |
60mm*2.0mm |
3.0M |
4.0M |
48mm*2.0mm |
60mm*2.0mm |
3.5M |
5.0M |
48mm*3.5mm |
60mm*3.5mm |
Light Duty Prop
|
MIN. |
MAX. |
Internal Tube |
External Tube |
1.6M |
3.0mm |
40mm*2.0mm |
48mm*2.0mm |
48mm*2.0mm |
56mm*2.0mm |
||
1.8mm |
3.5mm |
40mm*2.0mm |
48mm*2.0mm |
48mm*2.0mm |
56mm*2.0mm |
||
2.0mm |
3.5mm |
40mm*2.0mm |
48mm*2.0mm |
48mm*2.0mm |
56mm*2.0mm |
||
48mm*3.5mm |
60mm*3.5mm |
Product Description
1. Material: Q235 or Q255 or Q345
2. Surface: painted, powder coated, zinc-plated, hot dip galvanization
3. Specification: light-duty, heavy-duty, U base type, cross type, italy type, american type, spanish type
4. Sizes: 1) common adjustable range (closed-extended)
1.6m-2.9m,1.7m-3.0m,1.8m-3.2m,2.0m-3.6m
2.2m-4.0m,2.4m-3.9m,2.5m-4.5m,2.6m-5.0m
2) diameter range on tube (inner/outer)
dia. 40/48mm, dia.48/56mm, dia.48/60mm
3) thickness range on tube
1.6mm,1.8mm,2.0mm,2.5mm,3.0mm
4) top/base plate size
120x120x3.75mm/4.5mm/5mm
5. Inspection: by ourselves or by SGS or B.V or others
6. Certificates: ISO9001, EN74, BS1139
7. Packing: in pallets
8. OEM service is avaliable
9. Samples we can offer
