C-Frame Chemistry Laboratory Furniture Table Lab Bench Phenolic Top

C-Frame Chemistry Laboratory Furniture Table Lab Bench Phenolic Top thumbnail-1
C-Frame Chemistry Laboratory Furniture Table Lab Bench Phenolic Top photo-1
US$ 260 - 300 MOQ: 1 Meter
Key Specifications
Get Latest Price
Material:
Metal
Metal Type:
Other, Galvanized Steel
Size:
Customized Size, Customized Size
Contact Supplier Request Quote Chat Now
Shanghai Beta Laboratory Furniture Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Material Metal
Metal Type Other, Galvanized Steel
Size Customized Size, Customized Size
Place of Origin Shanghai, China
Brand Name Beta
Model Number Beta-B-S-06
Product Description

C-FRAME ALL STEEL STRUCTURE

C-FRAME provides a high level of stability for add-on tables, mobiles tables and analysis tables for working sitting or standing.


Steel framework, Fashion style with simple installation and flexible budget


Product Name
C-Frame all steel structure laboratory furniture
Structure
C-Frame ALL-Steel Workstation
Worktop
1）15 mm/19mm/20mm thickness EPOXY, Black Color

2）13mm/16mm/20mm/25mm thickness

3）304 STAINLESS STEEL cover with 25mm thickness MDF or Particle board core

4）WORK TOP: 20mm thickness of Laboratory Ceramics whose surface highly resistant to chemicals and well-suited for laboratories using very aggressive products. This is an extremely hard material resistant to scratches and resistant to high temperatures. The color: Black

Advantage of the 20mm thickness Laboratory Ceramic Work Top:

a: Chemical resistant

b: Be able to resist instant temperature 1200℃ and there is no affect when temperature is up to 160 ℃.

c: Durable and scratch resistant

d: Resistant to UV light

e: Resistant to ageing

f: Free from solvents, non-toxic and completely recyclable

7) 30mm thickness Marble, Black Color
C-Frame Steel
Worktops shall be supported by heavy duty steel frame work. Frame work shall be made of appropriate sections as given below made of cold rolled mild steel of thickness 1.5mm minimum which shall be sandblasted and Epoxy powder coated. Framework shall be designed for safe loading of worktops of up to 200 kilogram per square meter and to keep service space between wall and under bench units. Frames shall be connected to each other by means of a front runner of at least 2mm thick size 60x40mm. Frame shall be of rectangular box with a wall thickness of 3mm and at least of following dimensions.

Vertical member of minimum 60x40mm

Horizontal top member 60x40mm

Horizontal bottom member 60x40mm

Other frame sizes will be subject to approval.

All frame work shall be sand blasted, primed and Epoxy powder coated in required color to a thickness of 120-180 microns and hardened at 260 degree Celsius. Each cantilever leg shall have adjustable threaded foot of non abrasive material such as tough plastic, nylon etc.

Frame work shall be available in two heights, 750mm for sitting height and 900mm for standing height. Vertical member framework shall be with CNC punched slots for shelves/hanging cabinets. The total framework except for front and back shall be in one piece.
Cabinet
1) Cabinet are made of 1.0mm galvanized steel coated with epoxy resin powder.
2) Cabinets include adjustable corrosion resistant feet which provide support and acts as a vibration damper.
Handles
Integrated with door and drawer/304 Stainless Steel/Plastic
Reagent Shelf
1) The shelves are made of 1.2mm galvanized steel coated with epoxy resin powder.
2) layers are made of 12mm thickness tempered glass or 1.2mm galvanized steel coated with epoxy resin powder, can be adjustable according to different requirement
Faucet
Brass body with ceramic valve core coated with epoxy resin powder.
Sink
PP sink;ceramic sink; epoxy resin sink.
Socket
Electric sockets, electric circuit breakers and the telephone and computer outlets are located on this electrical trunking made of PVC and anchored to the shelf vertical supports
Drip cups
Drip cups can be made in different shapes and material depending on their location and task.
Detailed Images
Company Profile

We are a leading manufacturer and exporter. The products we provided like work bench, fume hood, storage cabinet are satisfied with the customers in Europe, Middle East, Africa and so on.


We are engaged in manufacturing and exporting laboratory furniture for many years which is mainly responsible for the laboratory design and installation.

BETALAB offers the widest selection of furniture and equipment for every discipline, enabling you to tailor your lab specifically and create your own lab system.
