aluminum film with kraft paper facing metallized polyester PET film
1. Description
Construction:
Aluminum Film/PETl |
12 microns |
Adhesive |
Polyethylene |
Kraft paper |
60gsm(Natural) |
Typical Physical Properties:
Properties |
Unit |
Value |
Test Method |
Basic Weight |
gsm |
87 |
ASTM D646 |
Burst Strength |
N |
98.8 |
ASTM D774 |
Reflective of Foil Surface |
% |
95 |
------------ |
Temp. Resistance |
-26℃ to 66 ℃ |
No Delamination |
ASTM C 1263 |
Water vapor |
ng/N.s |
<5.75 |
ASTM E-96 |
2. Application:
It could be used as packing paper, moisture proof, radiant barrier and easy to fold as your need.
Double-sided insulation is more effective and durable compared to the single-sided insulation, suit to insulate radiation caused by equipment like transformer signal station, it also be used for roof, wall and building insulation and also could be applied as facing onto rock wool, glass wool, plain slab, ceiling board, ducting air conditioning, or pipe section.
3. Dimension/Size:
[1]. Roll width: 1000mm,1200mm and 12500mm
[2]. Roll Length: 50m, 100m, 200m, 500m, 1000m, or upon request.
[3]. Core I.D.: 3"(76mm+/-1)
4. R&D:
We are developing flame retardant products and will meet market in Spring 2010.
(1) DFC1001: Double sided reflectiviy aluminum foil supply better perfomance and function.
(4) FSK7160-Tape: Applied pressure sensitve self adhesive and silicon coated paper to the kraft face of reflectivity aluminum scrim kraft facings, get the FSK TAPE.
(5) FSK7140, With metallized polyester film as the exposure surface instead of reflectivity aluminum foil, namely aluminum fil/ scrim/ kraft, for the purpose of maitain reflection with lower cost.
