Help Center2 Wing Automatic Revolving Door
Related Products
Specifications
2 wing automatic revolving door , Using brushless DC Motor, 2years warranty.passed CE and ISO 9001:2000, competitive price.2 wing automatic revolving door
Model |
CSD-RA2-30-E2 |
CSD-RA2-36-E2 |
CSD-RA2-42-E2 |
Internal diameter(mm) |
3000 |
3600 |
4200 |
external diameter (mm) |
3088 |
3688 |
4288 |
Channel width (mm) |
1500 |
1800 |
2100 |
Soomth door enterance(mm) |
900 |
1200 |
1500 |
Door crown height (mm) |
340 |
340 |
340 |
Overall height (mm) |
2640 |
2640 |
2640 |
Features:
*The frame is aluminum alloy, high intensity, and good degree of finish.
* Different decorative materials and colours are choosable, such as copper, stainless steel, copper, etc.
*High strength of alluminum structure, clean and clear surface.
*Laminated glass, tempered bending glass, flat tempered glass, special treated glass, etc.
*Radial ceiling boards can be made of assigned materials, and the color comforms with the unit.
*Canopy cover is made of wood or metal plates, and tight sealing treatment is applied.
*Energy saving, quiet, stable and with logn life-span.
*Digital control system, easy to operate.
*Various detecting functions, such as collision avoidance, anti-clamp, etc.
*Low speed for distabled.
* Automatic acceleration and adjustment.
* Automatic stop and positioning.
*The building fire alarm system can be connected to the door.
* Automatic stop and open when power is off.
*.Locking status can be realized by simple procedure and no need for extral e-mechanical bolts.
* Remote defect diagnose system can help the technicians determine and recover the door in time.
Components:
Alluminum profiles.
Curving and flat glass.
Driving system.
Sensing parts.
Decoration parts.
Technical parameters:
1. Power supply. AC220V50Hz
2. Servo motor. 250W*2
3. Sliding door power. 180W
5. Speed 1-4 RPM.( manual or auto adjustable)
6. Noise <42 db
7. Torque <2n.cm
