Automatic Swing Door Opener
- SHANGHAI OR NINGBO
- T/T
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | olide | |
| Model Number | SD2016 |
Product Description
Specifications
1.automatic swing door opener2.2 years warranty
3.remote control door
4.10 years experience
5.certification:ISO9001-2008,CE
automatic swing door opener
specification
Model | External SD2007 | Concealed SD2016 | External SD2108 | Concealed SD2008 |
Swing application | One-way open | One-way open | One-way open | Two-way open |
Door width | 900mm | 1000mm | 1200mm | 1000mm |
Door weight | 80kgs | 100kgs | 120kgs | 100kgs |
Opening speed | 3-8 seconds (adjustable) | |||
Closing speed | 3-8 seconds (adjustable) | |||
Time to open door | 0-120seconds (adjustable) | |||
Open angle | 70-150 degrees | |||
Closing buffer function | Adjustable | |||
Input power static/max | 5W/40W | |||
Buffer speed of opening | Adjustable | |||
Buffer speed of closing | Adjustable | |||
Buffer distance of opening | Adjustable | |||
Buffer distance of closing | Adjustable | |||
Braking force of opening | Adjustable | |||
Braking force of closing | Adjustable | |||
Locked power | Adjustable | |||
Power supply | AC220V,DC12V | |||
nology
Adpot german high tech, passed CE and ISO 9001-2000.Using brushless DC Motor, 2 years warranty.
2.advanced motor
Advanced brushless motor and worm wheel reducer are integrated,with lower consumption,energy saving, high efficiency, great torque and long life.with low noise, easy installation.
3Working procedures
Opening signal-control unlock - open - brake to stop door -keep the door open - self closing - buffer- locked.
ntroller
The door can be opened or closed by remote control, password swipe card reader,microwave sensor.body sensor, switch button.Intelligent control system with variable adjustable parameters.
5.safety
Automatic overload protection.Intelligent encountered obstacles protection, Intelligent over-temperature protection,Electric lock control function.The magnetic lock can be installed, make more secure.Safety beam protects the guest from bumping the door, safety and reliable.
6.adjustable
All models can be adjusted parameters by ajustable controller.
