Help CenterHX-ICS Belt Weighing Scale
Related Products
-
ICS Conveyer Weighing ScaleNegotiableMOQ: 1 Set -
100T Weighing Truck Scale/weighbrigeUS$ 8,000 - 9,000MOQ: 1 Set
-
10-200T Weighing Truck Scale/weighbrigeUS$ 8,000 - 9,000MOQ: 1 Set
-
TDG Speed Adjustable Quantitative Feeder Conveyor Belt ScaleNegotiableMOQ: 1 Set
-
Series ICS Electronic Belt ScaleNegotiableMOQ: 1 Set
Specifications
Using sealed bearing as the supportaccurate stable force transmission
fast zero return
no moving parts
less maintenance
Mechanical distortion for the whole system < 0.1mm.
Series HX-ICS Belt Scale System has an accuracy level of ±0.25%. It is specifically designed for plant and process operations to monitor production, regulate product loadout and to monitor product stock. It also provides critical information to assist in management of plant processes.
Series HX-ICS Belt Scale Belt Scale System combines the N63 Trunnion-type Weighbridge, the N60 Belt Speed Sensor and the 6101 Integrator. The load cells positioned on the weighbridge sense the belt load and transmit the analog weight value into the 6101 Integrator. The speed signal of the belt conveyor is also sent to the 6101 Integrator by the N60 speed sensor. Finally the totalization and instantaneous flow rate can be integrated after processing both the signals received by the 6101 Integrateor
Features:
Designed without moving or easy-worn parts to allow minimal requirement on maintenance.
Side force and horizontal component force resistant design reduces belt misalignment problems.
Robust tube steel construction ensures reliable calibration with minimal material buildup and zero drift.
Mechanical distortion for the whole system < 0.1mm.
Main Technical Parameters:
| Model No. |
Belt width |
Accuracy |
Weighing Range (t/h) |
inclination of belt conveyor |
Weighing Sensor |
Weighing roller (group) |
Voltage |
| ICS-A |
400~1400 |
±0.125 |
1-2000 |
≤6° |
4pcs |
4 |
220±10% |
| ICS-B |
400~1400 |
±0.25 |
1-2000 |
≤17° |
2pcs |
4 |
|
| ICS-C |
400~1400 |
±0.5 |
1-2000 |
≤17° |
2pcs |
2 |
|
| ICS-D |
400~1400 |
±0.5 |
1-2000 |
≤17° |
2pcs |
1 |
|
| ICS-E |
400~1400 |
±0.5 |
1-2000 |
≤17° |
1pc |
2 |
|
| ICS-F |
400~1400 |
±1.0 |
1-2000 |
≤17° |
1pc |
1 |
|
| ICS-G |
400~1400 |
±1.0 |
1-2000 |
≤17° |
2pcs |
1 |
