Atx Ps2 Power Supply 400w
US$ 50 - 500
MOQ: 50 Sets
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
ASPOWER
Model Number:
R2A-MV0700
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Atx Ps2 Power Supply for Tower PowerUS$ 50 - 500MOQ: 50 Sets -
1+1 Redundant 500W Power for PS2 Form FactorUS$ 50 - 500MOQ: 50 Sets
-
24pin Interface Type Desktop/Server/desktop Application pc Power SupplyUS$ 50 - 500MOQ: 50 Sets
-
Desktop Application and Stock Products Status ATX Power SupplyUS$ 50 - 500MOQ: 50 Sets
-
Hot-swap PC Power SuppliesUS$ 50 - 500MOQ: 50 Sets
Place of Origin
Guangdong, China
Brand Name
ASPOWER
Model Number
R2A-MV0700
Output Power
Other, 350w~700w
Output Type
Multiple
Input Voltage
Other, 90v~264v
Product Description
2U redundant power supply, which can be mianly used for tower type server and PS/2 compatible system; Module complete ouput is ATX group(AC&DC input are alternative). It supports with hot plug,hot backup. The conversion efficiency can be up to 80PLUS silver standard; The rated output power ranges from 400W to 700W. The dimension is L185XW150XH86mm.
| Model No | Watt | Module |
| R2A-MV0700 | 700 | U1A-M20700-DR |
| R2A-MV0650 | 650 | U1A-M20650-DR |
| R2A-MV0550 | 550 | U1A-M20550-DR |
| R2A-MV0450 | 450 | U1A-M20450-DR |
| R2A-MV0350 | 350 | U1A-M20350-DR |
| Input | Model No | Voltage | Frequency | Current(Unit:A) | Inrush Current | PFC | EMI | EMS | |||
| 115Vac | 230Vac | 115Vac | 230Vac | 115Vac | 230Vac | ||||||
| R2A-MV0700 | 100~240Vac | 50/60Hz | 10 | 5 | 35A | 70A | >0.98 | >0.95 | IEC-6100-3-2 FCC CISPR22(EN55022) | EN61000-4-2ESD EN61000-4-4EFT EN6100-4-5Surge | |
| R2A-MV0650 | 8 | 4 | 35A | 70A | >0.98 | >0.95 | |||||
| R2A-MV0550 | 6 | 3 | 35A | 70A | >0.98 | >0.95 | |||||
| R2A-MV0450 | 5 | 2.5 | 35A | 70A | >0.98 | >0.95 | |||||
| R2A-MV0350 | 4 | 2 | 35A | 70A | >0.98 | >0.95 | |||||
| Output | 80PLUS | Model No | Watt | 5 | ||||
| "+5V | "+3.3V | "12V1 | "-12V | 5Vsb | ||||
| 80PLUS BRONZE | R2A-MV0700 | 700 | 20A/30A | 20A/30A | 58A | 1A | 3A | |
| R2A-MV0650 | 650 | 20A/30A | 20A/30A | 54A | 1A | 3A | ||
| R2A-MV0550 | 550 | 20A/30A | 20A/30A | 45A | 1A | 3A | ||
| R2A-MV0450 | 450 | 20A/30A | 20A/30A | 37A | 1A | 3A | ||
| R2A-MV0350 | 350 | 20A/30A | 20A/30A | 29A | 1A | 3A | ||
| Regulation Load | ±5% | ±5% | ±5% | ±10% | ±5% | |||
| Ripple And Noise | 50mV | 50mV | 120mV | 120mV | 50mV | |||
| Remarks:+3.3V and +5V Total output power not exceed:120W,200W,-5V option | ||||||||
Company Information
ASPOWER is a professional solution partner of IT equipment in the United States, Focus on Research&Development as well as marketing.
In 2010, Shenzhen Honor Electronic hold ASPOWER brand, and completed the full acquisition in Feberary In 2011, the USA branch keep the Pre-reaserch and marketing as well as after-sale service.
In the beginning of 2011, IPC business department was set up in Shenzhen Honor, at the same time set up the R&D team. Most of the team members are from the first-tier power supply company like EMERSON, with much experience in designing PSU.At present engineer technical staff have 51,7 groups in hardware projects,2 groups in software projects, 1 group in backup on research(Structure,Layout,Component Recognition ,File Management File ,Design&Testing Group)
Aspower owns the three core business segments as following:
Server,Storage,Industrial control power supply:Including 1U~2U Single Power ,N+1 Redundant Power,all kinds of DC input Power supply.
Telecom Power:Its principal product is high-voltage DC remote system, including high-voltage DC source center,indoor end unit,outdoor end unit, and so on;
Non-standard customized power: providing customers with high stability, high efficiency, high reliability, non-standard industrial power supply solutions.
Packaging & Shipping
Normal Packing: 4sets packed into one carton, as per your requirement;
Shipping: By sea/By air;
Lead time:Within 30-45 workdays after plaing order;
Guarantee: 3 years
Factory Showing
Product Showing
mini redundant ps2 550W swithing power supply
Mini Redundant Power Supply module
