Road recovery vehicle tow wrecker car carrier truck for sale
3. Main parts of the vehicle like underlift and booms are adopted HG70 high strength wielding steel.
Advantages:
(1). Ensure the intensity and strength of these.
(2). Decreasing the curb weight so that reduce the fuel consumption.
Gross weight(Kg) |
25000 |
Drive type |
6X4 |
||||||
Curb weight(Kg) |
17400 |
Overall dimension(mm) |
10555X2500X3060 |
||||||
Approach/departure angle |
16/11 |
Cab seats |
2 |
||||||
Axle No. |
3 |
Front/rear hang(mm) |
1500/1880 |
||||||
Axle load(Kg) |
7000/18000 |
Wheelbase(mm) |
5825+1350 |
||||||
Max speed(Km/h) |
90 |
|
|
||||||
Chassis specification | |||||||||
Brand name |
SINOTRUK HOWO |
Dimension(mm) |
11700*2496*2958 |
||||||
Tyre specification |
11.00-20 |
Tyre No. |
10 |
||||||
Steel spring number |
10/12 |
Front track base(mm) |
2022 |
||||||
Fuel type |
Diesel |
Rear track base(mm) |
1830 |
||||||
Emission standard |
Euro 3 |
Transmission |
10 forward gear,2 reverse gear(manual) |
||||||
Cab |
HW76 flat top with air condition. |
||||||||
Engine model |
Displacement(ml) |
Power(Kw) |
|||||||
WD615.93E |
9726 |
213(290 HP) |
|||||||
Performance | |||||||||
Lifting system |
Max lifting capacity(kg) |
16000 |
|||||||
Fully extended max lifting capacity(kg) |
7310 |
||||||||
Effective length of the bracket arm(mm) |
1460 to 3099 |
||||||||
Bracket arm flexible stroke(mm) |
1639 |
||||||||
Hoisting system |
Max hoisting capacity(kg) |
18000 |
|||||||
Farthest hoisting capacity(kg) |
8000 |
||||||||
Max hoisting height(mm) |
6500 |
||||||||
Winch |
QTY(piece) |
2 |
|||||||
Rated traction for each(kN) |
100 |
||||||||
Steel wire rope diameter(mm) |
18 |
||||||||
Steel wire rope length(m) |
45 |
||||||||
- Car pick up truck / recover truck / flat road removal truck wrecker / tilt side truck
| 4 Axle 80 ton Low Bed Traler | 3 axle 60 ton Low Bed Trailer |
|
|
| 3 line 6 Axle Low Bed Trailer | Multi Axle Modular Trailer |
|
|
Order in this month , we will supply you 500 USD spare parts freely for you.
Welcome to contact us.
- The photos all rights reserved . Prohibited theft reserved
