long boom crane loader container trailer cimc box loader trailer

Name: long boom crane loader container trailer cimc box loader trailer
Brand: TITAN
Price: USD $80,000 - 100,000 / Unit

FOB Price

USD $80,000 - $100,000 / Unit

1 Unit(Min.Order)

Supply Ability 200 Unit / Units per Month
Port qingdao/shanghai
Payment Terms:T/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Type:	Semi-Trailer	Material:	Steel	Certification:	CE
Size:	1410025004100mm	OEM No.:	self loading container truck	Max Payload:	45T
Place of Origin:	Shandong, China	Brand Name:	TITAN	Model Number:	container side loader

Product Description

long boom crane loader container trailer cimc box loader trailer

Product Description

Factory direct sale with lower price and short delivery time ,also we will offer the free accessories.
we have exported more than 200 sets container side loader trailer to different countrys in 2015

Specification:

Container handling~ Lift Capacity up to 72,000 lbs
1 loaded 20 ft, / 2 30,000 lbs. each max
20 ft, 40 ft, 45 ft, (48 ft 53ft) loaded
We Stack Hi-Cube Containers 2 high ,
Containers can be weighed at your location
We transport LOADED / UNLOADED.

Video of contaier side loader

we have the advanced production line for the quality container side lift and every trailer will be tested before delivery.

Add to My Favorites

Some types of container side lifter we have exported to Africa market in this year.

For Djibouti market , December 2015 ( Overseas engineer to provide technical service)

For Zimbabwe market - July 2015

For Mozambique market - September 2015

Detailed Images

High Strength Trailer Chassis	Improve the stability of trailer when lifting heavy duty containers

-Wireless remote controller/Manual operatin	It can control trailer's legs and hanger within 30m , and also cut loading and off loading times significantly, Simple pictograms show the functions.

MAIN SPECIFICATION of self loading container truck trailer
Overall(LWH)	1410025004100mm
The distance between trailer and container	Optimum distance:400mm
The distance between trailer and container	The largest distance :1500mm
Side Lifter Specification	Design criteria: GB/T 3811-2008
Side Lifter Crane	Quality Side Crane
Max. lifting capacity	40000kg
Max.stabiliser outreach	3200mm
Max. working range	4000mm
Max. pressure of hydraulic	28MPa
Hydraulic system	Hydraulic pump: Italian CASAPPA
Electric control system	Hydraulic control valve: Netherlandish AMCA
	Telecontroller: German NBB
	Voltage: 12V
Two chain	Two chain: lgus (imported)
Diesel engine	Japanese Kubota diesel engine
Trailer Chassis	LWH:1410025004000mm
	Axles: 3*13 tons axles
	Tire: 12R22.5 tubless tire, 12 pcs
	Suspension:Heavy duty type mechanical suspension
	Kingpin:2 inch or 3.5 inch bolted type
	Landing gear: 28T
	Water-drenching device
Spare parts	Imported from Swedish
PRODUCT VIDEO ON YOUTUBE
https://youtu.be/a4hu3ejMzrQ (copy for watch)

Our Services

Safety:

• Double hydraulic safety provides safe lifting

• Lifting stops, if the support legs are not folded out

• Roll- and tip-proof with long support leg outreach

• Safe lifting; always four support points when stacking

• Tried and tested, user-friendly technology

Quality:

• in-house manufacture

• high tensile steel

• Low tare weight = high payload

• XCMG made quality crane

• Durable technology, easy to service

Service:

• Detailed operating instructions also ,we have the Video Explanation

• Overseas engineer to provide technical service

• You can reach us at any time and get a rapid response

• Competent technical service ,

• Rapid and safe deliveries of spare parts

Safety Order

Your safety business partner !

We support the Trade Assurance can guarantee the security of transactions !

Welcome To Contact

Welcome to contact with us. Any questions will get a timely response .

TITAN VEHICLE : Supplying the most durable truck trailer is our lifelong promise

More details information of self loading container truck trailer, welcome to contact at anytime!
