Specifications
40W 5V 8A ac/dc Power Supply S-40-5High reliability, a wide input range
High efficiency and low operation temperature
40W 5V 8A ac/dc Power Supply S-40-5
- S-40 series Industrial power supply
- Competitived price and high reliability
- 105oC Output capacitor
- AC input power suitable for the world
High efficiency and low operation temperature
Soft-start current can reduce the AC input impact effeciticly
With short-circuit and overload protection
Compact size, light weight
100% full-load burn-in test
Installed with EMI filter, minimum wave
| Model | S-40-5 | S-40-12 | S-40-15 | S-40-24 |
| DC output voltage | 5V | 12V | 15V | 24V |
| Output voltage rang(Note:2) | ±2% | ±1% | ±1% | ±1% |
| Rated output current | 8A | 3.5A | 2.8A | 1.8A |
| Output current range | 0-8A | 0-3.5A | 0-2.8A | 0-1.8A |
| Wave and noise(Note:3) | 75mVp-p | 100mVp-p | 100mVp-p | 100mVp-p |
| Inlet stability(Note:4) | ±0.5% | ±0.5% | ±0.5% | ±0.5% |
| Load stability(Note:5) | ±1% | ±0.5% | ±0.5% | ±0.5% |
| DC output power | 40W | 42W | 42W | 43W |
| Efficiency | 72% | 76% | 77% | 78% |
| Adjustale range for DC voltage | +10,-5% | +10% | +10% | +10% |
| Input current | 1.2A/115V 0.6A/230V | |||
| AC Inrush current | Cold-start current 30A/115V 60A/230V | |||
| Leakage current | <1mA/240VAC | |||
| Overload protection | 105%~150% Type: pulsing hiccup shutdown Reset: auto recovery | |||
| Over-voltage protection | 115%~135% | |||
| Temperature coefficient | ±0.03%/°c(0~50°c) | |||
| Setup, rise, hold up time | 800ms, 50ms, 15ms/115V 300ms, 50ms, 60ms/230VAC | |||
| Vibration | 10-500Hz, 2G 10min,/1cycle, Period for 60min, Each axes | |||
| Withstand voltage | Input and output internal 1.5KVAC, Input and enclosuer 1.5 KVAC, Output and enclosuer 0.5 KVAC | |||
| Working temperature and humidity | -10°c~+60°c. Refer to output derating curve, 20%~90% RH | |||
| Store temperature and humidity | -20°c~+85°c, 10%~95%RH | |||
| Weight | 0.45Kgs | |||
| Satety standards | UL 1012, TUV EN6050(IEC650, UL 1950) Approved | |||
| EMC standards | CISPR22(EN55022), IEC801-2,3,4, IEC555-2 Verfication | |||
|
Note: 1. The testing condition for the parameter above is: 230VAC input, rated load, 25 70% RH.Temperatuer. 2. Error: include the setting error, line stability and load stability.(Note:5). 3.Wave test: adopting "A12" double wire for 20 MHz, and 0.1 UF&47UF capacitor short-circuit for interrupting. 4. Inlet voltage stability test: wht is overload, the lowest voltage of inlet is up to the highest voltage. 5. Load stability test: The load is from 0% to 100% | ||||
Please be free to contact us for anything you concern.
