din rail switching power supply(DR-60-24)

Model

DR-60-5

DR-60-12

DR-60-15

DR-60-24

DC output voltage

5V

12V

15V

24V

Output voltage range(Note:2)

±2%

±1%

±1%

±1%

Rated output current

6.5A

4.5A

4A

2.5A

Output current range

0-6.5A

0-4.5A

0-4A

0-2.5A

Wave and noise(Note:3)

100mVp-p

200mVp-p

240mVp-p

480mVp-p

Inlet stability(Note:4)

±1%

±1%

±1%

±1%

Load stability(Note:5)

±1%

±1%

±1%

±1%

DC output power

32.5W

54W

60W

60W

Efficiency

72%

77%

77%

80%

Adjustable range for DC voltage

 4.75~5.5V

10.8~13.2V

13.5~16.5V

21.6~26.4V

AC input voltage range

85~264VAC 47~63Hz;120~370VDC

Input current

1.5A/115V 0.75A/230V

AC inrush curren

Cold-start current 30A/115V 60A/230V

Leakage current

<1mA/240VAC

Overload protection

105%~150% Type: pulsing hiccup shutdown Reset: tuto recovery

Temperature coefficient

±0.03%/°c(0~50°c)

Setup, rise , hold up time

800ms, 60ms, 50ms

Vibration

10~500Hz, 2G 10min,/1cycle, Period for 60min, Each axes

Withstand voltage

Input and output internal: Input and encolsur: 1.5KvAC, Output and enclosure: 0.5KvAC

Isolation resistance

Input and output internal: Input and enclosure, Output and enclosure:500VDC/100MΩ

Working temperature and humidity

-10°c~+60°c(Refer to output derating curve), 20%~90%RH

Overall dimension

78×93×56mm

Weight

0.3Kgs

Safety standards

Meet UL 1012 requiement (Not apply for the mark)

EMC standards

Meet FCC PART 15 J Conduction class B

Note:                                                                                                                                                  1. The testing condition for the paramenter above is: 230VAC input, rated load, 25°c 70% RH. Temperatuer.

2. Error: include the setting error, line stability and load stability.(Note:5).

3. Wave test: adopting "A12" double wire for 20MHz, and 0.1UF&47UF capacitor short-circuit for interrupting.

4. Inler woltage stability test: when is over load, the lowest voltage of inlet is up to the highest voltage.

5. Load stability test: The load is from 0% to 100%.
