0.1W 0.12W 0.2W 0.5W 13-65lm Pure,ware Natural Cold White , Smd 2835 Bridgelux , Epistar Chip Led

0.1W 0.12W 0.2W 0.5W 13-65lm Pure,ware Natural Cold White , Smd 2835 Bridgelux , Epistar Chip Led thumbnail-1
0.1W 0.12W 0.2W 0.5W 13-65lm Pure,ware Natural Cold White , Smd 2835 Bridgelux , Epistar Chip Led photo-1
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Model Number:
LD-2835
Chip Material:
InGaN
Emitting Color:
Natural White
Contact Supplier Request Quote Chat Now
Hunan Pusisat Opto Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Model Number LD-2835
Chip Material InGaN
Emitting Color Natural White
Luminous Intensity 13-65lm
Luminous Flux(lm) 13-65
Optical Attenuation(%) 1
Power 0.1W
Power Dissipation 1
Color Rendering Index(Ra) 70
Color Temperature 3800-5000
Place of Origin Hunan, China
Brand Name CHG
Certification CE

Specifications

0.1W 0.12W 0.2W 0.5W 13-65lm pure,ware natural cold white , smd 2835 bridgelux , Epistar chip led
Lowest price



0.2w 18-26lm pure white smd 2835 cree chip led

MichelleShi

Mob: 0086-15616609081

Skype:michelleshi1209





Production Description



Item

Spec

Commedity

0.2w 18-26lm pure white smd 2835 bridgelux , Epistar chip leds

Part No.

LD-2835

Color

warm white, natural white, pure white,cool white, red, yellow, green, blue,orange,purple and other colors you want

Chip brand

Bridgelux; Epistar

Lumens

13-36lm

Power

0.1w , 0.12w,0.2w 0.5watt

Current

40mA,60mA,150mA

Voltage

3.0-3.6v

CRI

>70

>75

>80

CCT range

2800-3200k (warm white)

4000-5000k (Natural white)

5000-6500k (Pure white)

>7000k (Cool white)

Working temperature

-20 C-+40 C

Super long lifetime

50,000 H

Max Junction Temperature

150C

Certification

CE, Rohs

Lowest thermal resistance

8C/W

Warranty

2 years

Place of Orign

China

Feature

Anti UV

Design

Superexcellent heat conduct design





Details Show



0.1W 0.12W 0.2W 0.5W 13-65lm pure,ware natural cold white , smd 2835 bridgelux , Epistar chip led







0.1W 0.12W 0.2W 0.5W 13-65lm pure,ware natural cold white , smd 2835 bridgelux , Epistar chip led







0.1W 0.12W 0.2W 0.5W 13-65lm pure,ware natural cold white , smd 2835 bridgelux , Epistar chip led





Attentions

1. Over-current-proof



Customer must apply resistors for protection; otherwise slight voltage shift will cause big current

change (Burn out will happen).



2. Storage



2.1 It is recommended to store the products in the following conditions

Humidity: 60% R.H. Max.

Temperature: 5C~30C(41F~86F)



2.2 Shelf life in sealed bag: 12 month at <5C~30C and <30% R.H. after the package is opened,

the products should be used within 24hr s or they should be kept stored at <20% R.H. with zip-lock sealed.



3. Vision Advisory Claim



Users should be cautioned not to stare at the light of this LED product. The bright light can damage the eye.





About Us





0.1W 0.12W 0.2W 0.5W 13-65lm pure,ware natural cold white , smd 2835 bridgelux , Epistar chip led0.1W 0.12W 0.2W 0.5W 13-65lm pure,ware natural cold white , smd 2835 bridgelux , Epistar chip led





Our Services



1. We have a special R&D center team, which can solve any problems for clients.

2. After sale service can help customers to dealing with any situations after sale.

3. Test all the products before packaging.

4. Two years gurantee time.

5. We also produce all kinds of indoor and outdoor lights.





If you want to know more details of our led beads or lights, pls send inquiry to me. Any feedback will be highly appreciated and replied.





0.1W 0.12W 0.2W 0.5W 13-65lm pure,ware natural cold white , smd 2835 bridgelux , Epistar chip led
