Disc Sintered Ferrite Magnet for CD-ROM

Name: Disc Sintered Ferrite Magnet for CD-ROM
Brand: MAS MAGNETICS
SKU: 133841633
Availability: InStock

Disc Sintered Ferrite Magnet for CD-ROM thumbnail-1

Disc Sintered Ferrite Magnet for CD-ROM thumbnail-2

Disc Sintered Ferrite Magnet for CD-ROM thumbnail-3

Disc Sintered Ferrite Magnet for CD-ROM thumbnail-4

Disc Sintered Ferrite Magnet for CD-ROM photo-1

Disc Sintered Ferrite Magnet for CD-ROM photo-2

Disc Sintered Ferrite Magnet for CD-ROM photo-3

Disc Sintered Ferrite Magnet for CD-ROM photo-4

US$ 0.05 - 0.25 MOQ: 10000 Pieces

Key Specifications

Get Latest Price

Place of Origin:

Anhui, China

Brand Name:

MAS MAGNETICS

Model Number:

Y10T~Y40

Contact Supplier Request Quote Chat Now

Ma'anshan Baiyun Environment Protection Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Anhui, China

Brand Name MAS MAGNETICS

Model Number Y10T~Y40

Type Permanent

Composite Ferrite Magnet

Shape Other, round,disc,cylinder

Application Industrial Magnet

Sintered Ferrite Magnet

Brief

Sintered Ferrite is sintering magnetic materials. Main Components are SrO or BaO and Fe2o3, According to different processing technology , it can be divided into isotropic and anisotropic. Isotropic magnet has lower property, but it can be magnetized through to every side of magnet; anisotropic magnet has higher property, but they only can magnetize through predesigned magnet size.

Applicant

Our magnets are mainly used for loud speaker, microwave oven, D C motor, instrument and apparatus, mechanical equipment , art work and toys so on.

Characteristics

Characteristic: High working temperature

Strong ability of resistance to demagnetization ,

Not easy to be oxidized

Applying Shapes

Sintered Ferrite Magnet Performance and Grade

Grade	(Br)		(HcB)		(HcJ)		(BH)max
Grade	mT	KGauss	KA/m	KOe	KA/m	KOe	KJ/m3	MGOe
Y10T	200~235	2.0~2.35	125-160	1.57-2.01	210-280	2.64-3.51	6.5-9.5	0.8-1.2
Y22H	310~360	3.10~3.60	220-250	2.76-3.14	280-320	3.51-4.02	20.0-24.0	2.5-3.0
Y25	360~400	3.60~4.00	135-170	1.70-2.14	140-200	1.76-2.51	22.5-28.0	2.8-3.5
Y26H-1	360~390	3.60~3.90	200-250	2.51-3.14	225-255	2.83-3.20	23.0-28.0	2.9-3.5
Y26H-2	360~380	3.60~3.80	263-288	3.30-3.62	318-350	3.99-4.40	24.0-28.0	3.0-3.5
Y27H	350~380	3.50~3.80	225-240	2.83-3.01	235-260	2.95-3.27	25.0-29.0	3.1-3.6
Y28	370~400	3.70~4.00	175-210	2.20-3.64	180-220	2.26-2.76	26.0-30.0	3.3-3.8
Y28H-1	380~400	3.80~4.00	240-260	3.01-3.27	250-280	3.14-3.52	27.0-30.0	3.4-3.8
Y28H-2	360~380	3.60~3.80	271-295	3.40-3.70	382-405	4.80-5.08	26.0-30.0	3.3-3.8
Y30H-1	380~400	3.80~4.00	230-275	2.89-3.46	235-290	2.95-3.64	27.0-32.5	3.4-4.1
Y30H-2	395~415	3.95~4.15	275-300	3.45-3.77	310-335	3.89-4.20	27.0-32.0	3.4-4.0
Y32	400~420	4.00~4.20	160-190	2.01-2.39	165-195	2.07-2.45	30.0-33.5	3.8-4.2
Y32H-1	400~420	4.00~4.20	190-230	2.39-2.89	230-250	2.89-3.14	31.5-35.0	3.9-4.4
Y32H-2	400~440	4.00~4.40	224-240	2.81-3.01	230-250	2.89-3.14	31.0-34.0	3.9-4.3
Y33	410~430	4.10~4.30	220-250	2.76-3.14	225-255	2.83-3.20	31.5-35.0	3.9-4.4
Y33H	410~430	4.10~4.30	250-270	3.14-3.39	250-275	3.14-3.45	31.5-35.0	3.9-4.4
Y34	420~440	4.20~4.40	200-230	2.51-2.89	205-235	2.57-2.95	32.5-36.0	4.1-4.4
Y35	430~450	4.30~4.50	215-239	2.70-3.00	217-241	2.73-3.03	33.1-38.2	4.1-4.8
Y36	430~450	4.30~4.50	247-271	3.10-3.40	250-274	3.14-3.44	35.1-38.3	4.4-4.8
Y38	440~460	4.40~4.60	285-305	3.58-3.83	294-310	3.69-3.89	36.6-40.6	4.6-5.1
Y40	440~460	4.40~4.60	330-354	4.15-4.45	340-360	4.27-4.52	37.6-41.8	4.7-5.2

Production Process

Quality System

With its own strict quality control system and advanced detection equipment, MAS MAGNETICS has been successively certified by ISO9001, ISO9000 and TS16949 quality system.
