Product Details
| Condition | New | Type | Other, Magnetic Separator | |
| Place of Origin | Anhui, China | Brand Name | Baiyun | |
| Model Number | YC-80-1 | Voltage | 380 V | |
| Power(W) | 0.75KW | Dimension(L*W*H) | 1470*920*1040 mm | |
| Certification | ISO 9001:2000 | Warranty | 1 year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
YC Dry Drum Magnetic Separator
Brief
YC dry drum magnetic separator can attract dry magentic powder from the non-magnetic materials continuously and automatically.
The unique desigh for magnetic circuit and the magnetic source is made up from the NdFeb with high performance. Featuring with powerful magnetic forece and high efficiency for tramp iron-elimination, it can be widely arranged in the lines such as grinding,fire-proofmaterial,foodstuff,feed,buildingmaterial,ceramics,raw material for glass, renewable rubber powder, PVC powder, quartz sand,and chemical industry and so on. Feeding capacity can be adjusted to meet the different granularity requirement. It is characteristic with exempt-maintenance,energy saving, cost-lower,safety and reliability.
Feature
Magnetic material
High-density Ceramic permanent magnet is standard. Rare Earth magnets are available.
Magnet design
Stationary Ceramic or Rare Earth magnetic assembly inside rotating drum shell.
Contaminant removal
Ferrous fragments, nuts, bolts, and other tramp metal from free-flowing granular material.
Method of cleaning
Continuous self-cleaning design.
General material
Stainless steel drum cover with mild steel housing. Stainless steel housing is optional.
Installing Position
YC- Dry Drum Magnetic Separator may be installed in many different places in your process.
Main Dimension and Technical Data
| Model | External Size (mm) | Drum Spec (mm) | Magnetic Intensity (GS) | Quantity of Roller | Capacity(T/H) | Size Limit (mm) | Power(kw) |
| YC-40 | 840X460X660 | 300X400 | >=3000 | 1 | <=0.5 | <=5 | 0.55 |
| YC-50 | 940X460X660 | 300X500 | >=3000 | 1 | <=0.6 | <=5 | 0.55 |
| YC-60-1 | 1040X460X660 | 300X600 | >=3000 | 1 | <=1.5 | <=5 | 0.55 |
| YC-60-2 | 1040X460X1240 | 300X600 | first roller>=1000 Second roller>=3000 | 2 | <=2 | <=5 | 2x1.5 |
| YC-80-1 | 1470x920x1040 | 500x800 | >=3000 | 1 | <=2 | <=8 | 0.75 |
| YC-80-2 | 1710x1320x1570 | 500x800 | first roler>=1000 second roller>=3000 | 2 | <=2.5 | <=8 | 2x1.5 |
| YC-100-1 | 1590x1020x1240 | 500x1000 | >=3000 | 1 | <=2.5 | <=10 | 1.1 |
| YC-100-2 | 1910x1420x1770 | 500x1000 | first roller >=1000 second roller>=3000 | 2 | <=4 | <=10 | 2x2.2 |
Note: We can develop the products according to the customers’ demands, too.
YC Dry drum magnetic separator
Client Visiting
FAQ
1.How do you get the suitable models ?
A: Please send more details about your minerals , such as : the raw minerals , the raw grade ,finally grade you want , minerals size ,the handling capacity you want .
Or send some samples to our factory , we will do experiment for your minerals . Then we will recommend the suitable models for you .
2.How long is the product warranty period ?
A: We will guarantee the new equipment one year. Within guarantee period, we will supply relative damaged parts. While you need to maintain the equipment periodically according to our instruction, in that case, the equipment can work for a long time without malfunction. Over the guarantee period, we will supply the parts according to the market price.
Warmly welcome to visit our factory and company any time you like it!
