Specifications
1.RGB LED Controller:2.Voltage: DC12V/24V,5v
3.dimming and changing color
4.RF/IR/Wireless Controller
5.CE and ROHS
LED DMX signal RGBW wall panel DMX controller
We have more than 50 kinds RGB LED Controller, RGB LED controller adopts the advanced micro-control unit,it is used for controlling a variety of lamp whose source of light is LED. For instance, point source of light, flexible light strip, wall washer lamp, glass curtain wall light and so on; It has many advantages such as easy connection and simplicity to use. According to the actual need of customers, it can carry out jumpy changing,gradual changing,stroboflash and other effects of change.
Technical parameters:
1.RGB/rgbw part:
1. Wireless Controller( RF20B )
1.Working temperature:-20-60 °C
2.Supply voltage: DC12-24V(order Indicate required voltage)
3.Size: 84*64*23 mm Package size: 200*146*36mm
4.Net weight: 78g Gross weight: 200g
5.0utput: 3 channel Output current : <5A(each channel)
nnection mode: common anode Static power: : <1W
7.Output power: 12V< 180W, 24V<360 W
2. Wireless Controller( RF20C)
1.Working temperature:-20-60 °C
2.Supply voltage:DC12-24V(order Indicate required voltage)
3.Size: 84*64*23 mm Package size: 200*146*36mm
4.Net weight: 75g Gross weight: 197g
5.0utput: 2 channel Output current : <5A(each channel)
nnection mode: common anode Static power: : <1W
7.Output power: 12V< 120W, 24V<240 W
3. RGB controller with keys
24keys/28keys/44keys
1.Work temperature: -20-60°C
2.Supply voltage: DC5V, 12-24V(order Indicate required voltage)
3.Size: 63*35*22mm Package size: 105*65*40mm
4.Net weight:50g Gross weight: 70g
5.Launch and receive frequency: 433.92MHZ
6.Output: Three CMOS drain open-circuit output
7.Static power: <1W Output current: <2A( each channel )
8.Connecting mode: common anode common cathode
9.Output power: 5V:<30W, 12V:<72W, 24V:<144W
4.2.4G controller
5. Programming controller
1.Work temperature: -20-60°C
2.Supply voltage: DC5V, 12-24V(order Indicate required voltage)
3.Size: 94*58*26mm Package size: 145*95*50mm
4.Net weight:130g Gross weight: 155g
5.Launch and receive frequency: 433.92MHZ
6.Output: Three CMOS drain open-circuit output
7.Static power: <1W Output current: <4A( each channel )
8.Connecting mode: common anode common cathode
9.Programming functions (maximum compiled 20 steps)
10.Output power: 5V: <60W, 12V: <144W, 24V: <288W
RGBW controller
1. Working temperature:-20-60 °C
2.Supply voltage: DC12-24V(order Indicate required voltage)
3.Size: 85*45*22 mm
4.Net weight: 78g Gross weight: 200g
5.0utput: 4 channel Output current : <6A(each channel)
nnection mode: common anode
7.Output power: 12V< 288W, 24V<576 W
2.Music controller
3.wifi controller
Trade term:
1. Payment:T/T,Western Union, MoneyGram
2. Production lead time for 100pcs 2 days;1000pcs 7 days
3. MOQ:10pcs
Our Service:
1. Your inquiry related to our products and prices will be replied in 24hours.
2. OEM and ODM, any your customized controller we can help you design.
