2012 hot sale air slide conveyor belt / conveyor belt / cement air slide belt
1.High speed of removing ash, no ash left
2.Easy to use.
3.High performance
4.low cost
Specification:
| 1. Major Specification | |||||||||
| Item No | Material | Layer Number | tensile strength | Elongation | Temerature Resistance | Thickness | Weight | Width | Air resistance |
| SFF4-5 | 100% polyester | 4 | 360 | 270 | 180-200 Deg C | 5-5.5MM | 3600G | 2000MM | ≥4500 |
| SFF4-6 | 100% polyester | 4 | 360 | 270 | 180-200 Deg C | 6MM | 4000G | 2000MM | ≥4500 |
Its other name is airslide conveyor or aero cloth or airslide canvas. We can produce 2mm to 10mm thickness type.The Air-Slide consists of a rectangular chamber separated by a permeable cloth. The chamber is inclined at a very slight angle (as low as 1.5°). Compressed air is injected into the lower chamber which then permeates through the media and “fluidises” the product. The product then behaves like a fluid and “flows” down the length of the chamber. The excess air is vented to a dust collector.Air slide Fabrics are used to transport solids with a high flow rate over long distances. Air slides provide an efficient, low energy system with minimum maintenance. They are available with multiple inlets and multiple outlets by use of integrated segment valves.
| 2. Main Material | |||||||||
| High Strength Polyester and Aramid fibers | |||||||||
| 3. How It Works | |||||||||
| Air slide Conveyer uses the forces of gravity to do most of the work without any moving parts. Material is fluidized through a porous media with low pressure air. Material flow is achieved by sloping the Airslide conveyor to match the fluidized angle of repose of the powdered material. At the correct slope, fluidized materials flow with the consistency of a liquid. Airslide Air Gravity systems provide highcapacity material handling while offering many economical and environmental advantages. Energy requirements are minimal because only a small volume of air at a low pressure is required to move material. Since the system is installed overhead, valuable floor space and added headroom are available for other purposes. By eliminating the need for massive support members, it permits a flexibility of plant design not available with straight-line conveyors. The Airslide conveyor is dust tight. As a result, the system is extremely friendly to the environment. | |||||||||
| 4. The Applicable Scope | |||||||||
| As the powder material and particle material conveying equipment of the core material, air slide fabric is mainly used for the air transport of powder material and granular materials in the filed of homogenization library, pneumatic lift pump, bulk tank car, metallurgy, chemical industry, steel mills, power plants, etc. | |||||||||
| 5. Advantages and Features | |||||||||
| 1)Main material for large tonnage bulk material tank car and horizontal activities cement bin | |||||||||
| 2)Can replace breathable layer. | |||||||||
| 3)Make the capacity of tanks larger | |||||||||
| 4)High speed of removing ash, no ash left | |||||||||
| 5)Easy to use and replace. | |||||||||
| 6)Hgh performance, low cost | |||||||||
| 7)Extremely friendly to the environment |
As a filtration equipment supplier with many years of experiences, we supply all kinds of air dust filter bag, woven and non woven filter fabric, filter bag sewing machine and related products. In addition, we supply all kinds of liquid filter fabrics, filter bags and bag making
For more information,you can call me or email me (Jenny). Let us talk more, thanks !
