Home > Products > chain machine > Alloy Studded Chain Welding Machine
Alloy Studded Chain Welding Machine
- Shanghai
- T/T
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | Polywin | |
| Model Number | CE01W-75 |
Product Description
top quality chain welding machinery
The application are lifting round chain welding, also many kinds of round chain such as snow chain, decorated chain, lashing chain, mining chain.
Technical Data:
No. | Item | Specification |
1 | Wire diameter |
3-6mm |
2 | Pitch of link chain | 11-30mm |
3 | Output, chain links | 45-50pcs/min |
4 | Rated load succession rate | 20% |
5 | Transformer Power | 75KVA |
6 | Motor Power | 3KW |
7 | Rated speed | 852-1704 |
8 | Rotary encoder | 600 rpm |
9 | Secondary no load voltage | 4-10v |
10 | Pressure of cooling water | 0.15-0.3MPa |
11 | Cooling water | 20 liters/min. |
12 | Cooling water temperature | 15-25C |
13 | Air Supply Pressure | 0.65Mpa min. |
14 | Pneumatic working pressure | 0.45-0.65MPa |
15 | Air consumption | 5 liters/working cycle |
16 | Power | 80 KW |
17 | Size | 1.8X0.95X1.5m |
18 | Weight | 2MT |
We also supply chain bending machine, chain calibration machine, chain tensile test machine and chain heat treatment machine etc. as a one-stop service for our customers.
