Feng Hua DS-50 Fog Cannon Suppresses Dust Concentrations Loading/unloading Trucks Transfer by Conveyor Belt Unloading Hoppers

Feng Hua DS-50 Fog Cannon Suppresses Dust Concentrations Loading/unloading Trucks Transfer by Conveyor Belt Unloading Hoppers photo-1
Feng Hua DS-50 Fog Cannon Suppresses Dust Concentrations Loading/unloading Trucks Transfer by Conveyor Belt Unloading Hoppers photo-2
Feng Hua DS-50 Fog Cannon Suppresses Dust Concentrations Loading/unloading Trucks Transfer by Conveyor Belt Unloading Hoppers photo-3
Feng Hua DS-50 Fog Cannon Suppresses Dust Concentrations Loading/unloading Trucks Transfer by Conveyor Belt Unloading Hoppers photo-4
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
feng hua
Model Number:
DS-50
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name feng hua
Model Number DS-50

feng hua DS-50 fog cannon suppresses dust concentrations loading/unloading trucks transfer by conveyor belt unloading hoppersfeng hua DS-50 fog cannon suppresses dust concentrations loading/unloading trucks transfer by conveyor belt unloading hoppers



feng hua DS-50 fog cannon suppresses dust concentrations loading/unloading trucks transfer by conveyor belt unloading hoppers



Why us:

*industrial water cannon with remote control cabinet and high pressure pump easy to handle

*water mist cannon for dust control with dry fog system optional without saturating the ground too much

*water cannon for sale from direct factory, offered with competitive price



Cerficates:

  feng hua DS-50 fog cannon suppresses dust concentrations loading/unloading trucks transfer by conveyor belt unloading hoppers





Product Description:

The feng hua DS-50 industrial water mist cannon for dust control coal mine use for sale generates a mist/fog of fine water droplets, which will form mass gravity with the particles to achieve the dust suppression effect. Water cannons with range from 30 - 200m avaiable, contact us for more details.





Technical Parameters

Model

DS-50

Max Throw

50m no wind

Volume Flow (Adjustable)

16~30L/min

Fog Droplet Size (Adjustable)

50~150um

Horizontal Rotation Angle

180°Manual,  360°Automatic

Pitching Angle

-10°~90°

Water Pressure

1.5~3.5MPa

Overall Dimensions (L*W*H)

L150*W145*H210(cm)

Sprayer Tank (Optional)

According to customer's requirements

Vehicle Matching

Agricultural vehicle,truck,watering cart,trailed vehicle, etc.





Product advantage & Feature
1. Professional manufacturer with over 20 years' experience, high quality, best service and competitive price, offer multiple choices of product to meet different requirements.
2.Strong capability, high & far throw range, wide coverage area, achieve precise volume spraying, high efficiency and spray speed.
3. Micro fog droplet, form a wet mist touching the floating dust, high speed knock down the dust.
4. Flexible power: three-phase 380V and diesel generator power supply optional
5. Flexible installation, fixed on the concrete platform or diesel generator-powered vehicles optional.
6. Flexible, safe & reliable to use. Remove control & manual control operation. Easily adjust the spray angle of horizontal rotation.
7. Compare to tank car, water consumption save 70% ~80%, wide coverage area.





Application:



  • Ø        Quarries and mines; Haul roads, processing plants and Stock piles;
  • Ø        Iron and Steel Making: Stock piles and Slag bays;
  • Ø        Cement factories;
  • Ø        Demolition;
  • Ø        Crushing machines;
  • Ø        Storage and handling of bulk materials;
  • Ø        Discharge hoppers;
  • Ø        PORTS: Points of loading and unloading ships;
  • Ø        Conveyor belts and transfer of material areas;
  • Ø        Recycling facilities;





Working View

feng hua DS-50 fog cannon suppresses dust concentrations loading/unloading trucks transfer by conveyor belt unloading hoppersfeng hua DS-50 fog cannon suppresses dust concentrations loading/unloading trucks transfer by conveyor belt unloading hoppersfeng hua DS-50 fog cannon suppresses dust concentrations loading/unloading trucks transfer by conveyor belt unloading hoppersfeng hua DS-50 fog cannon suppresses dust concentrations loading/unloading trucks transfer by conveyor belt unloading hoppers
