1. Principle & Characteristics
S11 Series three phase oil immersed transformer with load series comply with national standard GB1094 Electrical Power Transformer and GB/T6451 Technical Parameters and Requirements for Three Phase Oil Immersion Type Power Transformer. Voltage regulation range with load: 10±4×2.5%KV,35±3×2.5%KV, Voltage regulation range without excitation:10±2×2.5%KV,35±2×2.5%KV. By using with load switch and no excitation regulation switch, regulate voltage in the regulation range manually, electrically or automatically to ensure stability of output voltage. On the body of transformer, there are three positioning points at upper, middle and lower, and there are also loose proof and shock proof measures, so that there is no need to lift core and check before installation and it is shock proof. Oil tank is made of high quality steel plate, with high mechanical strength. Rubber stripe and rubber mad are made of latest high quality acrylate product which won’t age even after long period of operation and as a result effectively prevent oil leakage.
2.Features
1. Standard: IEC60076, GB1094-1996; JB/T10088-2004; GB/T6451-2008; EQV
2. Voltage Grade: 6KV to 35KV
3. Voltage Regulation Mode: No-load tap changing or On-load tap changing
4. Tapping Range: ±5%, ±2×2.5%, ±4×2.5% or others
5. Frequency: 50Hz; 60Hz
6. Phase: three phase
7. Connection Sign: Dyn5,Dyn5,Yyn0, Dyn11 or others
8. Short Circuit Impedance: Standard impedance (For details see technical data sheet)
3.Parameter & Specifications
4. Products Pictures
5.Why to choose us
1.Low MOQ: As we are the OEM , small MOQ can be accepted
2.Good Quality : We have strict quality control system .Good reputation in the market.
3.Special design: Special requirement can be accepted ,we have professional designers .
4.Good service : We treat clients as friends .
5.Fast & Cheap Delivery: We have big discount from forwarder (Long Contract).
