1. Principle & Characteristics
The structure of the TDJA /TSJA single phase / three phase series induction voltage regulator is similar to the conventional vertical wound rotor asynchronous motor. When the relative position of stator is changed, the inductive potential phase( three phase) of stator winding will be changed, also the inductive potential amplitude(single phase), which ensures output voltage in a certain range. When the output voltage is beyond the range of rating accuracy, directly or indirectly take the output signal voltage of voltage regulator, by comparison with the reference voltage of voltage stabilizing controller, after amplification, the servo motor of voltage regulator drives reversible operation so that the output voltage can reach the rated value automatically in a certain accuracy range.
2. Scope of Application
TDJA /TSJA automatic induction voltage regulator is suitable for automatical molding machine, Low-pressure die casting machine, gravity casting machine, furnace, core shooting machine, mixing sand machine, abrator,etc..Widely used in plumbing, sanitaryware, car spares, vaives, iron cast lines, etc..
3.Features
1.Non-contact adjustment, long service time
2.Suitable for different kinds of load
3.Strong over-load ability
4. perform reliably,convenient to use and maintenance
4.Parameter & Specifications
5.Why to choose us
1.Low MOQ: As we are the OEM , small MOQ can be accepted
2.Good Quality : We have strict quality control system .Good reputation in the market.
3.Special design: Special requirement can be accepted ,we have professional designers .
4.Good service : We treat clients as friends .
5.Fast & Cheap Delivery: We have big discount from forwarder (Long Contract).
6. Contact information
