Perfect Product!!BINZUAN 200m Truck Mounted Drilling Rig

Perfect Product!!BINZUAN 200m Truck Mounted Drilling Rig thumbnail-1
Perfect Product!!BINZUAN 200m Truck Mounted Drilling Rig photo-1
US$ 1 - 120,000 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
BINZUAN
Model Number:
BZC200CA
Contact Supplier Request Quote Chat Now
Shandong Binzhou Forging And Pressing Machinery Factory
Payment & Shipping
Payment Methods:
Port of Shipment:
all of Chinese ports
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name BINZUAN
Model Number BZC200CA
After-sales Service Provided Engineers available to service machinery overseas

Specifications

Chassis:CHANA Truck, this truck is famous in China
Drive form:6*4
Color:white,red,green and the others
Power:132kw

Main features:

1.BZC200CA truck mounted drilling rig is designed by our engineers; it  adopts truck mounted and is a rotary drilling rig.
2.The truck chassis  adopts  the 6X4 special  crane chassis of brand CHAN'AN TRUCK , the main transmit, transmission power, gearbox, sets of windlass, mud pump, sewage pump,mast are set up on the chassis.
3.This rig is a rotary drilling rig with directional circulation, which is equipped with BW850/2A mud pump, It adopts the slurry as the washing fluid, it can drill on clay, sand and rock if it is equipped with a good drilling bit.
4. The power of drilling rig comes from the truck engine, the rig sets up distribute implement and hydraulic system.
5. We can set up the spare electric engine and clutch implement according to client's requirement, so that the rig can work with diesel engine or electric engine.
6. One set of 100Kw generator has been set on the chassis, it will supply the power to drilling rig, and it is convenient to illuminate or work at night.
7. The adding pressure device is hydraulic, so it has a high efficiency when the rig drill on mud rock and weathering formation through using the adding pressure implement.
8. The master driving of rig is mechanical, the four jacks and mast are hydraulic operated. Distribute box, sewage pump, master driving clutch system are air operated.
9. The appearance of rig is pretty, it has a high efficiency because of having a larger torque of the turntable, it is mainly used for water well, construction, national defense building foundation, geological exploration, geothermic well and other foundation working, it is popular with domestic and foreign clients.


Technical parameter



 Drilling depth(M)

200



 Drilling diameter(mm)

500



 Speed of turntable(r/min)

6.7;10;17;43;63;108(reverse)



 Torque of turntable(KN.m)

14.5;9.7;5.7;2.3;1.5;0.9(reverse)


 Single rope lifting capacity of mian windlass(KN)

30



 The capacity of main windlass(KN)

 180



 Single rope lifting capacity of hydraulic windlass(KN)

30



 The capacity of hydraulic windlass(KN)

120



 The lifting capacity of hook(KN)

180



 Bearing capacity of mast (KN)

180



 The height of mast (mm)

10200



 Bearing capacity (t)

25



Pipe

 Kelly bar(mm)

108×108×6000



 Assistant pipe (mm)

89×10×4500















BW850/2A

plunger pump



 Diameter of cylinder (mm)

150



 Stroke of piston (mm)

180



Theory of flow (L / min)

600      850



Rated pressure (Mpa)

3         2



Pounding  times (min-1)

58        82



 Diameter of suction tube (mm)

127



 Diameter of drain pipe (mm)

64



 Input speed (r / min)

470



 Input power (kw)

40



 Overall dimensions (mm)

2000*1030*1400



Weight (t)

1.5









Truck chassis

 Drive form

6×4





Engine

 Model

YC6J180-33 (Europe II emission standard)



 Rated power(KW)

132



 Speed (r/min)

2500



 Size (L*W*H)(mm)

100320×2400×3200



Electric generator

Rated power (kw)

100



Rated voltage(v)

400



Speed (r/min)

1500



Frequency(Hz)

50



 The highest speed(Km/h)

75



 Weight (kg)

17340



 Transport size(L*W*H)(mm)

10252*2400*3726



 Working size(L*W*H)(mm)

10032*3570*11459
