drilling rig for 300meter well

FOB Price

USD $680,000 - $720,000 / Set

1 Set(Min.Order)

Supply Ability 200 Set / Sets per Month
Port Qingdao Port/Tianjin Port
Payment TermsCredit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Rotary Drilling Rig
Power Type	Diesel	Place of Origin	Shandong, China
Brand Name	BINZUAN Drilling rig	Model Number	BZC-350ZYII
Usage	Water Well	Weight	20t
Certification	ISO9001	Warranty	one year
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Specifications

we are a professional drilling machine factory which builded 1953.

Main features

BZC-350ZYII water well drilling rig is designed by our engineers; it is adopt truck mounted and is a rotary drilling rig.

The truck chassis is adopt the special crane chassis of brand SINOTRUK, the main transmit, transmission power, gearbox, sets of windlass, mud pump, sewage pump,mast are setup on the chassis.

This rig is a rotary drilling rig with directional circulation, which is equipped with BW850/20A mud pump, It adopts the slurry as the washing fluid, it can drill on clay, sand and rock if it is equipped with a good drilling bit.

The power of drilling rig comes from the truck engine, the rig setups distribute implement and hydraulic system.

Technical parameter
Drilling depthM			80	300
Drilling diametermm			1500	500
Speed of turntabler/min			1810.63.82.522.7reverse
Torque of turntableKN.m			21.236100.618516.8reverse
Single rope lifting capacity of windlassKN			30
the max torque of whole machineKN.m			40.55
The lifting capacity of hookKN			180
Bearing capacity of mast (KN)			180
The height of mast (mm)			11500
Bearing capacity (t)			25
Pipe	Kelly mm		108×108×7500
	Assistant pipe (mm)		89×10×5500
Hydraulic pump	Model		CB-HP50/32Z
	Pump delivery (ml/r)		50/32
	Rated speed (r/min)		3500-3700
	Rated pressure(MPa)		20
BW850/2A plunger pump	Diameter of cylinder (mm)		150
	Stroke of piston (mm)		180
	Theory of flow (L / min)		600 850
	Rated pressure (Mpa)		3 2
	Pounding times (min^-1)		58 82
	Diameter of suction tube (mm)		127
	Diameter of drain pipe (mm)		64
	Input speed (r / min)		470
	Input power (kw)		40
	Overall dimensions (mm)		200010301400
	Weight (t)		1.5
Truck chassis	Model		TAZ5183TZJ
	Drive form		6×4
	Engine	Model	TBD226B-6
		Rated powerKW	132/2300rpm
		Speed r/min	2300
	Size LWH(mm)		11420×2500×2500
Electric generator	Model		MF
	Rated power (kw)		15
	Rated voltage(v)		400
	Rated current(A)		27
	Speed (r/min)		1500
	Frequency(Hz)		50
	Protection level		IP21
	Insulation Class		H
The best working gear (or speed)			5^thgear1000-1400r/min
The highest speedKm/h			75
Weight kg			19340
Transport sizeLWH(mm)			11420×2500×3440
Working sizeLWH(mm)			11420×2500×13100
