car parking system

car parking system

AX301-20 tilt parking lift is designed of two spaces of up and down as one unit. The bottom car can go in and out directly. When the upper space needs to park a car, the car in the bottom should be driven out.

Product advantage

The maximum lifting height can be 1750mm. The maximum lifting weight is 2000kg. This type parking lift is available for sedan.

The upper platform can inclines to make full use of the space. Compared with the net height of other 2-level parking equipment, the net height of our equipment is required to be not less than 3100mm or 2900mm.

The device size is according to customer’s requirement.

Hydraulic drive, chain balancing device to ensure the balance both ends of rise and fall.

Vehicle platform fully enclosed design to avoid oil leakage polluting the bottom car.

Structure all adopts laser cutting, attractive appearance, easy installation, less questions, easy maintenance.

It can be widely used in hotels, enterprises and public institutions and residential area.
