BL-0701A New Style Delay Switch

60PCS/carton

dealy Switch can be programmed to turn itself on automatically at any time of a 24-hour
period of five hours and then turn itself off.

Main functions:

Step 1 Switch on/off

Touch once the panel for on, again touch once for off.

Touch the panel once for off and then immediately replace your hand (within one second) and keep it in place. The light controlled by the dimmer switch will begin to flash on and off.

Each flash sets the “on time” for one additional hour from the present time.

Count the flashes until the required “on time” is reached and then remove you hand. (LED will flash continuously to indicate timer is active .)

  For example, if you are programming the switch at 8am and you wish the light to switch on at 6pm, count ten flashes.

Step 3 To cancel timer function

Under the condition of the lamp Extinguishes ,

Touch three the panel to cancel timer function.

( the lamp display from off —on—off—on ).

Step 4 Dimmer

If you wish you can set the light to dimmed level by simply retouching and maintaining contact with the dimmer switch until the desired light level is reached.

Note: The lamp off within one second not to be able to adjust the light

Step 5 Setting “delay off”

Delay off will be based on delay on for realizing.

the lamp bright condition,Touch the panel once for off and then immediately replace your head ( within 1 second ) and keep it in place.

The light controlled by the dimmer switch will flash on and off

Each flash sets the “off time” to an additional 15 minutes from the time the light is switched on.

Count the flashes until the required “delay off time” is reached and then remove hand . (LED will flash continuously to indicate is active)

  For example, if you have programmed the switch delay on at 6pm and you wish the light to switch delay off at 8pm, count eight flashes.
