88 Inch Interactive Electronic Whiteboard Interactive Whiteboards

Technical Items

Technical Specification

Software

Model

BL-9089HD

1.export PDF PPT HTML

Product Dimensions

1770*1260mm

2.paste,rotate,locking

Writing size

1710*1200mm

3.full screen,screen record

Package Size

1905*1385*120mm

4.insert documents,flash,video

Gross Weight

22kg

5.change background color

6.smart pen,text

7.move,magnifier,cover,searchlight

Temperature

-10°Cto50°C

8.mathematical diagram and table

Humidity

30-80%

etd.

Projection Gain

Available

Viewing Angle

170 degree in Horizon

160 degree in Vertical

Surface Material

Imported PET film

Induction way

Electromagnetic Induction

Hardware

The Induced Objects

Special electronic pen

Aluminum frame

Power Input

USB power supply (no extra power)

Current consumption

100mA

Signal Interface

USB2.0

USB cable connection can support maximum length

10m

Transmission Speed

12M/s

Anti-light intensity

Use under direct sunlight

Scan speed

The first point 25 ms, consecutive points 8 ms

Cursor speed

180 points / sec

Display resolution

4096*4096                                                                      (Depends on the actual computer and projector resolution)

Single PCB technology,stable and perfect maintenance

Support projection display ratio

4:3

Accessories

Wall-mounted Annex

INCLUDED

Electronic Pen

INCLUDED

Interactive Whiteboard Software

INCLUDED

Installation User-guide

INCLUDED

USB cable

INCLUDED

Lifetime

10 years

Warranty

3 years

Delivery time

7work days after received deposits
