8" Rack Mount Industrial Lcd Display With Aluminum Bezel With IP 65

8" Rack Mount Industrial Lcd Display With Aluminum Bezel With IP 65 thumbnail-1
8" Rack Mount Industrial Lcd Display With Aluminum Bezel With IP 65 photo-1
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Products Status:
Stock
Type:
Industrial Monitor
Brand Name:
Anrecson or OEM
Contact Supplier Request Quote Chat Now
Shenzhen Anrecson Electronics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Hongkong or Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Products Status Stock
Type Industrial Monitor
Brand Name Anrecson or OEM
Model Number LC-MI0801R

Feature Descriptions:



1.Aluminum bezel with IP 65



2. Various of Sizes range from 5" to 46"( such as 5”,7", 8", 10.4", 12.1", 15", 17", 19", 20", 21.5", 22", 24", 26", 32", 37", 40", 42", 46" etc.), with 1.5 years’ warranties
3. Optional touch screen: 4-wire/5-wire Resistive, Infrared, SAW, Capacitive, with USB or RS232 touch screen interface.



4. With CE, RoHs, FCC, ISO 9001 approved



5. Wide temperature from -20 to 80 degree



6. Color of 16.7M make image more natural, fine and smooth.



7. Customized service is available



8. Long life span. Support 24hours all day and 365 days continuous heavy burden work



9. Applicable to ATM, kiosk, transportation, automatic vending machine, POS, gaming machine, medical device, etc, industrial areas



Data sheet:



Specification
8" Industrial Monitor( Racked Mount)
Mode Name LC-MI0801R
Screen Size 8″
Active Display Area (mm) 162mm(W)×121.5mm(H)
Display Mode 4:3
LCD Type TFT-LCD
Resolution 800×600
Display Color 16.7M
Pixel Pitch(mm) 0.0675(H)×0.2025(V)
Brightness(nits) 250cd/m2
Contrast Ratio 500:1
Viewing Angle 140(H) /120(V)
Response Time 10ms
Backlight LED backlights
Interface D-Sub15 pin(VGA),DVI,HDMI
Power DC12V 2A   50HZ/60HZ
Power Consumption <=10W (Max)
Plug & Play DDC 1/2B
OSD Control Auto adjust, Brightness, Contrast, Hori. / Vert. Position, Clock, phase, Color, Language..
MENU Chinese/English(other languages supported)
Mount Way
Mounting Racked Mount
Optional Mounting Way VESA 75mm/100mm
Certificate Approval CE,RoHS,CCC,FCC,ISO9001
Warranty 1.5 years
Application
ATM/ Kiosk/Transportation/ Industrial Automation/Medical Treatment

 8" rack mount industrial lcd display with Aluminum bezel with IP 658" rack mount industrial lcd display with Aluminum bezel with IP 658" rack mount industrial lcd display with Aluminum bezel with IP 65
