Specifications
1.high recovery rate:diesel 87%.2.no need clay,acid, alkali.
3.used oil recycle diesel.
4.catalyst distillation.
JNC Waste engine oil regeneration Distillation apparatus
1. Overview
This machine can be used in black engine oil,Crude oil and plastic oil, to get gasoline and diesel oil through distilled catalyst. Pump into the heater with Waste oil which was pretreated, through the coal (or fuel oil) heating to working temperature, after catalytic distillation, can obtain the required of gasoline and diesel oil. When the reaction of waste oil in reactor is completed, stop heating, remove residue in the tank bottom, it can be reused.
2.Systems of equipment
1) Reaction tank:
Waste oil after be pretreated, pumps into this tank.
2) Heating system:
Through burn coal or fuel oil make oil temperature up to setting value, equipped with insulation system.
3) Catalytic system:
Waste oil reaches the predetermined temperature, via catalytic effect; gaseous hydrocarbons become gasoline and diesel composition.
4) Cooling system:
Gasoline and diesel which through catalytic be condensed into a liquid material.
5) Temperature control system:
Ensure that waste oil transforms into gasoline and diesel oil, waste oil dried by distillation, can stop heating timely.
6) Exhaust gas handling system:
A small amount of non-liquefied gas via treatment, can meet emission standards.
3. Indicators of oil after treatment:
1,diesel oil : 85-88%;
2,gasoline: 3-4%;
3,Kerosene: 2-3%;
4,oil residue: 3-4%.
4.Oil sample:
5.Advance:
JNC Series Used Engine Oil Recycle Diesel Plant
1.Principle: Catalyst distillation to get 0# diesel.
2.No need clay, alkali,acid refining.Present LY Plate Pressure Oil Filter to purify Output oil.
3. Low cost in the later phrase--catalyst reagent cost only usd 11/ton.
4.Vacuum distillation, sealing mixing system is more life-longer.
5.Color index <2.0.
6. Diesel 85-88% , gasoline 5-6%, oil residue about 6-8%.
7.Heati by gasoline or gas, more convenient,economic,safe, healthy and eco-friendly.
