TLA-100 Light Fuel Oil Filter Machine,Portable Oil Purifier Plant
It currently adopts the most advanced principles of Coalescence-separation in world, collecting filtration precision ,efficient demulsification and dehydration in one.TLA light fuel oil purifier series can remove a large amount water without heating the oil, can fast separate water from the oil that has the equal amount of oil and water, and after treatment the cleanliness level up to NAS6, the water content in oil up to 50ppm. It is not easy to rust when use the oil after filtration to clean the bearings, lower costs, and the oil can be reused, compact design, simple and easy to operate. Basically it is non-wearing for parts, low maintenance costs, small energy consumption, and the trolley-style design is convenient for the movement of equipment.
Technical parameters:
Items | Unit | TLA-10 | TLA-20 | TLA-30 | TLA-50 | TLA-80 | TLA-100 | TLA-200 | |
Flow | L/min | 10 | 20 | 30 | 50 | 80 | 100 | 200 | |
Working pressure | Mpa | ≤0.3 | |||||||
Water content in oil | PPM | ≤50 | |||||||
Cleanliness | NAS | ≤6 | |||||||
Working noise | dB(A) | ≤55 | ≤65 | ≤85 |
| ||||
Power | KW | 0.75 | 0.75 | 0.75 | 2.2 | 2.2 | 3 | 6 | |
Dimension | mm | 700 | 700 | 700 | 800 | 800 | 1000 | 1500 | |
570 | 570 | 600 | 650 | 650 | 700 | 1000 | |||
550 | 600 | 650 | 750 | 800 | 850 | 1200 | |||
Dimension and weight will be changed with changing the technical specification.
If this product is not your required,We also have other products:
ZL series of high-efficient vacuum oil purifier
ZLA Two-Stage Vacuum Oil Purifier Series
ZLC Two-Stage Multi-Function Vacuum Oil Purifier Series
ZLQ Series automatic pressure test vacuum purifier
TZL Turbine Oil Purifier
TZL-B Turbine Oil Purifier
RZL Lubricating Oil Purifier
RZL-B Series Lubricating Oil Purifier
ZSC Engine Oil Purifier Series
TLA light fuel oil purifier series
JL Portable-type Oil Purifier
LY Plate Pressure Oil filtering Machine
JNC Waste engine oil and black oil regeneration diesel oil equipment
