Usage:
JL portable-type oil purifier is fit for oil-using departments and corollary equipments. It can be used in the filtration of mechanical impurity, and high-lift and long-distance oil pumping and oil injection.
Characteristics:
----This machine has three filtrations whose filtering element gradually becomes intensive. It is portable, easy-handling, without filter paper and environment protection. It can not only filter the impurity of oil but also satisfy the high-lift and long-distance oil pumping and oil injection.
Technical Parameters
Model | JL-30 | JL-50 | JL-70 | JL-100 | JL-150 | JL-200 | JL-250 | JL-300 | |
Flow L/min | 30 | 50 | 70 | 100 | 150 | 200 | 250 | 300 | |
Lift | 5m | 8m | 8m | 10m | 12m | 15m | 15m | 15m | |
Filter precision | 5µm | 5µm | 5µm | 5µm | 5µm | 5µm | 5µm | 5µm | |
Total Power (kw) | 0.55 | 0.75 | 1.1 | 2.2 | 3 | 3 | 4 | 4 | |
Power | 50HZ 380V | ||||||||
inlet (outlet) diameter | Made according to the customers demand | ||||||||
mm Dimension | L | 560 | 650 | 650 | 700 | 700 | 800 | 800 | 800 |
W | 450 | 500 | 500 | 550 | 550 | 580 | 580 | 580 | |
H | 450 | 500 | 500 | 550 | 550 | 580 | 580 | 580 | |
Attention:Dimension and weight will be changed with changing the technical specification.
