Specifications
1,High precision stainless steel net is used2,Novel structure and good layout
3,Very straight and evident effect
ZSC waste lubricating oil recycling purifier
Through many years’ hard work, the Company successfully developed the ZSC series engine oil purification and discolourization purifier, which is a breakthrough in oil depolarization--a worldwide difficulty. This purifier can remove the tiny impurity dispersed in oil such as carbon particles and deep oxides, as well as bad substance such as colloid and asphalting. Thus, the clarity of oil recovered, engine oil quality is improved, performance of engine is restored, abrasion reduced. These would ensure correct operation of lubricant system of an engine and extend the life time of engine oil and engine as well. This kind of purifier is applicable to purification of various engine oil used for transport facilities such as ship and automobile.
2,Features:
( 1)It is a physiochemical application to eliminate the electric charge between polar particulate in waste oil, which is gathered into large particles and separated. The colloid, asphalting and other compound in oil are also removed while harmful gas and the water content are removed by the waste gas cleaner and the vacuum degasses function. Thus, the oil is cleaned and the effective constituent of oil is retained.
( 2)High precision stainless steel net is used, which is anti-corrosive, high temperature resistant and has a good mechanical strength and long lifetime. It is easy to use, and utilizes the economical pressure filter as filter medium.
( 3)Novel structure, good layout and is deemed as a “Mini Refinery”.
( 4)Very straight and evident effect and the machine can be used for multiple purposes.
( 5)Can be tailored to meet the needs of an individual customer.
3,oil sample comparision
4,application
It is suitable for marine, automotive, oil and other lubricants kowtow processing
5,technical parameters
Name |
Unit |
ZSC-10 |
Handling Capacit |
Ton/day |
10 |
Recovery rate |
% |
83~86% |
Color Grade |
|
≤3 |
Flash Point |
°C |
≥220(according to the oil) |
Acid Value |
KOH mg/g |
≤0.1 |
filter precision |
μm |
≤5 |
moisture content |
PPM |
National standard(trace) |
working noise |
db(A) |
≤70 |
oil pump pressure |
Mpa |
≤0.4 |
power supple |
|
380V/50HZ(can be adjusted as the requirement of users) |
Heating power |
KW |
144 |
Total Power |
KW |
165 |
Heating time |
Hour |
2 |
Filtering surface area |
m2 |
30 |
Long * high *wide |
mm |
14000*2100*2500 (Exhaust system highest sition3600mm) |
Total Weight |
KG |
7500 |
Container model number |
|
1 40GP AND 1 20GP |
