ZL series of high-efficient vacuum oil purifier is case-hardened product of electric power industry.
ZL series of high-efficient vacuum oil purifier
-Usage:
It is widely used in power plant, hydropower station, electric power company, metallurgy, petrifaction, railroad, etc. It can purify unqualified transformer oil, mutual-inductor oil, switch oil and capacitor oil, also rapidly dehydrate, degasify and purify oil. Meanwhile, it also has the function of drying electric machine and injecting oil to electric equipment.
---Characteristics:
A: Super dehydration and degasification system. We adopt large cubage to rapidly separate water and gas from oil.
B: Reliable heating system to ensure heating and stable oil temperature.
C: Precise filtration system adopts high-grade filtration materials which has advantages of good mechanical intensity, multi-level filtration, gradually intensive and high filtration precision system.
D: Advanced pressure protection device and infrared control system can avoid the influence of wrong operation.
E: Integration has chain security protection. It can automatically control the oil pressure and oil level.
F: This machine can be used with BZ series of transformer oil discoloring device together to add the function of acid-removing, discoloring, uncombined carbon removing, and reducing damage.
Technical Parameters:
Model |
Unit |
ZLA-20 |
ZLA-30 |
ZLA-50 |
ZLA-70 |
ZLA-100 |
ZLA-150 |
ZLA-200 |
|
|
Rated flow |
L/min |
20 |
30 |
50 |
70 |
100 |
150 |
200 |
|
|
Vacuum Range |
Mpa |
-0.05~-0.099 |
|
|||||||
Temperature Range |
°C |
40~80 |
|
|||||||
Oil pump pressure |
Mpa |
0.05~0.3 |
|
|||||||
Total Power |
kw |
33 |
38 |
46 |
62 |
90 |
120 |
144 |
||
Power |
|
50HZ 380V |
|
|||||||
Working Noise |
db(A) |
≤65~85 |
|
|||||||
Cleanliness |
NAS1638 |
≤NAS 6 |
|
|||||||
Breakdown Voltage |
kv |
≥75 |
|
|||||||
Water content in oil |
PPM |
≤3 |
|
|||||||
Gas content in oil |
% |
≤0.05 |
|
|||||||
Filter precision |
µm |
≤3 |
|
|||||||
Inlet (outlet) diameter |
|
25 |
25 |
32 |
32 |
42 |
50 |
60 |
|
|
|
Dimension(mm)
|
L |
1380 |
1480 |
1670 |
1820 |
2000 |
2100 |
2200 |
|
|
W |
870 |
980 |
1100 |
1200 |
1300 |
1400 |
1600 |
|
||
H |
1000 |
1200 |
1500 |
1500 |
1600 |
1800 |
1800 |
|
||
This is our catalogue for you to choose:
RZL lubricating oil purifier
RZL-B series lubricating oil purifier ---especially for removing large amount of water in oil
ZLA two-stage Vacuum oil purifier series
ZL series of high-efficient vacuum oil purifier
TZL turbine oil purifier
ZLC two-stage Multi-Function Vacuum oil purifier series
KL phosphate Ester Fire-Resistant oil filter machine series
JL portable-type oil purifier
LY plate pressure oil filtering machine
ZSC waste engine oil purifier
JNC waste engine oil regeneration distillation apparatus
