Help CenterKL Fire Rersistant Oil Filter Machine
Related Products
-
FIRE-RESISTANT OIL FILTER MACHINE SERIES/Oil Purifier in Machine Oil PurifierUS$ 15,000 - 23,500MOQ: 1 Set -
KL Phosphate Ester Fire-resistant Oil Filter Machine SeriesUS$ 8,000 - 150,000MOQ: 1 Set
-
KL Phosphate Ester Fire-resistant Oil Filter Machine SeriesUS$ 15,000 - 17,000MOQ: 1 Set
-
KL Phosphate Ester Fire-resistant Oil Filter Machine SeriesUS$ 7,000 - 15,000MOQ: 1 Set
-
FIRE-RESISTANT OIL FILTER MACHINE SERIESUS$ 15,000 - 23,500MOQ: 1 Set
Specifications
1.applied to phosphate ester fire-resistant oil system and mechanical equipment2..remove water, gas
KL fire rersistant oil filter machine
KL series use pure physical approach for dehydration, degassing, deacidification, decolorization and impurity removal treatment, which does not affect the oil and service performance. At the same time, it sets the precision oil filter, efficient dewatering, degassing, a three-dimensional vacuum evaporation technology and automatic control technology in one. It is simple to operate and runs safely and reliably. It can effectively guarantee the normal operation of oil equipment to avoid the accident.
Characteristics
1.The equipment contact parts with the oil pipelines and the tanks all using stainless steel (2Cr13) materials
2.Designed to take full account of phosphoric acid fuel characteristics of fire resistant oil, low temperature operation
3.Its has strong ability to filter out impurities.
4.Deacidification and decolorization are obvious
5.Equipment protection devices are well-established
Technical Parameters
Model |
KL-10 |
KL-20 |
KL-30 |
KL-50 |
KL-70 |
Rated Flow(L/min) |
10 |
20 |
30 |
50 |
70 |
Vacuum Range |
-0.05~-0.099Mpa |
||||
Temperature Range |
40~65°C |
||||
Oil pump pressure |
0.05~0.3Mpa |
||||
Power Supply |
50HZ 380V |
||||
Total Power |
20 kw |
27.5 kw |
35 kw |
49 kw |
65 kw |
Working Noise |
≤80 db(A) |
||||
Gas content in oil |
≤0.1 % mgkoH/g |
||||
Water content in oil |
≤400ppm |
||||
Cleanliness |
≤NAS 6 |
||||
Mechanical impurity |
no |
||||
Dimension(mm) |
600×480×850 |
700×480×900 |
800×480×950 |
900×500×1000 |
950×500×1000 |
