Huaheng Industry’s brite tanks is a vertical, cylindrical vessel for beer storage and serving. The tank has a cooling zone and is fitted with adjustable legs.
Name |
Service Tank |
Type |
Vertical, cylindrical, cooled, pressurised |
Material |
AISI 304 Stainless steel |
Surface Finish |
2B – cold-rolled, annealed, pickled |
Insulation |
Polyurethane foam |
Top Shape |
Domed |
Bottom Shape |
Domed |
Legs |
Adjustable |
Glycol Cooling Zone |
In the cylindrical section; connection G 3/4“ |
Vessel Pressure |
3 bar |
Cooling Zone Pressure |
1.5 bar |
Sanitation Arm |
DN 25 with DN 40 valve |
Beer Intake and Discharge |
DN 40 with DN 40 valve – lower bottom |
Sprinkler |
Removable |
Inspection Opening |
Oval shape |
Vacuum Safety Valve |
DN 50 fitted to upper bottom |
Overpressure Safety Valve |
DN 25 fitted to upper bottom, preset to 3.0 bar |
Handling Eyelets |
2 |
Spigot |
DN 15 |
Valves |
DN 40, 2 units |
Temperature Sensor |
Needle type PT – 100, 2 units |
Manometer |
DN 25 fitted to sanitation arm |
CO2 Saturator |
DN 25 with DN 50 discharge |
Level Gauge |
Glass tube in metal case |
- Full Name: Zhejiang Huaheng Industry Co., Ltd
- Founded: 1990
- Registered Offices: Fuyang, Hangzhou, P. R. China
- Main Business Activity: Design, Manufacturing of Stainless Steel Tanks for Food& Beverage, Brewery & Winery, Dairy Industry etc.
- Quality Managing System: ISO9001:2008
- Employees: about 145
- Manufacturing facilities: CNC Lathe, Shearing machine, Rolling Machine, EWM Welding machine, Polishing machine, Blasting room etc
- Production Area: 20.000 sqm
We invite you for a no-obligation tour of our facilities to see for yourself what makes Huaheng Industry a different in manufacturing craft beer equipment for brewing industry!
Before any piece of craft beer brewing equipment leaves Huaheng Industry, it goes through a complete quality control inspection. This inspection assures your equipment meets all specifications and is in proper working order before it leaves our facility and arrives at your door.
Any further questions or requirements, please feel free to contact us:
TEL: +86-571-2329 8092
FAX: +86-571-2329 8080
E-mail: austin# (please replace “# ” with “@”)
Skype: austine123
We are looking forward to hearing from you!
